Главная Каталог товаров KTM EPC 2014 KTM Street KTM 2014 Naked Bike KTM 2014 Street 1290 SUPERDUKE R BLACK ABS 14 (F9975N2) [US] KTM FRAME

FRAME

FRAME

Например: 61303001000EB

1

61303001000EB

Frame 613Na Electr.-Orange

242 934 ₽/шт

2

6030300500033S

Engine Supportl/s Black

11 122 ₽/шт

3

6030300600033S

Engine Support R/s Black

11 122 ₽/шт

4

0035100249

SHCS M10x24 TX45

5

0035100609S

AH-COLLAR SCREW M10X60 ISA45

6

0433100003

WASHER 18x10,5x1,6

7

6900314010033S

Footrest front left

8

6900314110033S

Footrest front right

9

6130303800033S

Footrest Plate Fr. L/s

13 282 ₽/шт

10

6130303900033S

Footrest Support Front R/s Bl

13 685 ₽/шт

11

0035080256

AH-COLLAR SCREW M8X25 ISA45

12

60003044100

footrest bolt, rear

13

61003042000

SPRING FOOTREST FRONT 05

14

0799060003

retaining washer DIN 6799 - 6

15

61304076000

CHAIN SLIDING BLOCK-FRAME

16

61111064000

TAMPER-PROOF SCREW 07

17

61007014000

SPACER FUEL TANK 05

18

50307014000

TANK ROLLER 12X26X12 98

19

0025060106

Vis

20

6130300210033

Sube Frame Black

100 982 ₽/шт

21

6130304800033S

Footrest Support Rear L/s Bl

12 154 ₽/шт

22

6130304905033S

Footrest Mounting Rear Black

3 406 ₽/шт

24

60003052000

ENGAGE PANEL FOOTREST R/S 03

26

6900305013333S

Footrast back left cpl.

27

0035080206S

HCS M8x20 TX45

28

6130304900033S

Footrest Support Rear R/s Bl

10 850 ₽/шт

29

6900305113333S

Footrast back right cpl.

30

6130300203033S

Cross Brace Rear Black

8 891 ₽/шт

31

61303002040

RUBBER GROMMET

32

61303088000

PLUG SFL 22X0,8-3,0

33

0025080166

Vis

34

83008100015

Vis (spec)

35

69008021060

Vis (spec)

36

60004017000

SCREW M14X1,5 L=73MM 03

37

69008021080

clip nut M5

38

0025080206

Vis

39

0125080003

Rondelle

40

60003152000

ENGAGE PANEL FOOTREST L/S 03

41

61303091000

KNEE PAD L/S

42

61303092000

KNEE PAD R/S

43

60303010000

BUSHING MOTOR MOUNTING

44

61303085000

FRAME COVER L/S

45

61403086000

FRAME COVER RIGHT

46

0025080356

Vis

49

61011094000

CABLE TIE WITH PLUG M6

50

47106003060

QUICK RELEASE CLUTCH

51

61003088000

PLUG SFL28 05

Узлы для 1290 SUPERDUKE R BLACK ABS 14 (F9975N2) [US] KTM

FRONT FORK, TRIPLE CLAMP

FRONT FORK, TRIPLE CLAMP

FRONT FORK DISASSEMBLED

FRONT FORK DISASSEMBLED

HANDLEBAR, CONTROLS

HANDLEBAR, CONTROLS

SIDE / CENTER STAND

SIDE / CENTER STAND

SHOCK ABSORBER DISASSEMBLED

SHOCK ABSORBER DISASSEMBLED

FRONT BRAKE CONTROL

FRONT BRAKE CONTROL

REAR BRAKE CONTROL

REAR BRAKE CONTROL

FRONT BRAKE CALIPER

FRONT BRAKE CALIPER

REAR BRAKE CALIPER

REAR BRAKE CALIPER

LIGHTING SYSTEM

LIGHTING SYSTEM

INSTRUMENTS / LOCK SYSTEM

INSTRUMENTS / LOCK SYSTEM

EVAPORATIVE CANISTER

EVAPORATIVE CANISTER

SEPERATE ENCLOSURE

SEPERATE ENCLOSURE

ANTIBLOCK SYSTEM ABS

ANTIBLOCK SYSTEM ABS

WP SHIMS FOR SETTING

WP SHIMS FOR SETTING

CRANKSHAFT, PISTON

CRANKSHAFT, PISTON

SECONDARY AIR SYSTEM SAS

SECONDARY AIR SYSTEM SAS

TRANSMISSION I - MAIN SHAFT

TRANSMISSION I - MAIN SHAFT

TRANSMISSION II - COUNTERSHAFT

TRANSMISSION II - COUNTERSHAFT

SHIFTING MECHANISM

SHIFTING MECHANISM

CYLINDER HEAD REAR

CYLINDER HEAD REAR

CYLINDER HEAD FRONT

CYLINDER HEAD FRONT

LUBRICATING SYSTEM

LUBRICATING SYSTEM

IGNITION SYSTEM

IGNITION SYSTEM

ELECTRIC STARTER

ELECTRIC STARTER
