FRAME

FRAME
Например: 7720300100004
1
7720300100004
FRAME
2
77203002000
SUB FRAME SX
3
78003002010
SUB FRAME APPLICAT. LEFT 08
4
78003002020
SUB FRAME APPLICATION R/S 08
5
77203013000
REINFORCING B. 350 SX-F
6
60011093075
RUBBER CABLE TIE 75MM 03
7
77207012000
TANK REST RUBBER
8
0025080166S
Vis
9
57013072100
WIRING HOLDER 16MM
12
77203014000
engine brac.scr. M10x115
14
0019080206S
Vis (Flat M8x20)
15
56530079000S
Hh Collar Screw M8X44 Ws13
184 ₽/шт
16
54803092050
BLIND PLUG-IN NUT M5 WN 22A 03
17
44011076305
CABLE TIE 300/4,8MM BLACK
18
0738050250
COU.SUNK SCR. AH ISO7380 M5X25
19
54803092060
BUSH F. FRAME PROTECTION 03
20
44011076140
CABLE TIE 140/2,5MM BLACK
25
54310086200
Nut (M8x10,9)
26
54310086100
SELF LOCKING NUT M10 CU WS=14
27
0025080306
Vis
28
0125060003
WASHER DIN0125-A 6,4
29
0025060256
Vis
36
78003040050
FOOTREST L/S 08
40
78003041050
FOOTREST R/S 08
41
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
42
54603041000
FOOTREST SPRING L/S & R/S
43
0125100003
washer DIN 125 A 10.5
44
0094032253
PIN DIN0094-3,2X25 STEEL
45
5030314013390
Footpeg l.+r. cpl. 03
19 843 ₽/шт
46
50303089000
ANGLE PIECE '97
47
55007016001
PVC-HOSE 7X10 PER METER
50
77203096000
SPROCKET COVER 350 SX-F
59
77203053000
CHAIN SLIDER LOWER PART CPL.
62
77303139000
BLIND RIVET NUT EM6-60LF/HX
63
77203094000
PLASTIC FRAME PROTECTION SET
64
77203053010
CHAIN SLIDING KIT BELOW CPL.11
99
77203096010
SPROCKET COVER KIT
