FRAME

FRAME
Например: 5480360110033
1
5480360110033
Frame Black M. 548L4
168 640 ₽/шт
2
77203002000
SUB FRAME SX
3
78003002010
SUB FRAME APPLICAT. LEFT 08
4
78003002020
SUB FRAME APPLICATION R/S 08
5
54803613000
REINFORCING 250 SX CPL.
7
77207012000
TANK REST RUBBER
8
59001037000
Vis (spec)
9
0934080003
Nut
12
54603013000
engine brac.scr. M10x105 WS13
14
0019080206S
Vis (Flat M8x20)
15
56530079000S
Hh Collar Screw M8X44 Ws13
184 ₽/шт
16
54803092050
BLIND PLUG-IN NUT M5 WN 22A 03
17
44011076140
CABLE TIE 140/2,5MM BLACK
17
44011076305
CABLE TIE 300/4,8MM BLACK
18
0738050250
COU.SUNK SCR. AH ISO7380 M5X25
19
54803092060
BUSH F. FRAME PROTECTION 03
25
54310086200
Nut (M8x10,9)
26
54310086100
SELF LOCKING NUT M10 CU WS=14
27
0025080306
Vis
28
0025060306
Vis
36
78003040050
FOOTREST L/S 08
40
78003041050
FOOTREST R/S 08
41
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
42
54603041000
FOOTREST SPRING L/S & R/S
43
0125100003
washer DIN 125 A 10.5
44
0094032253
PIN DIN0094-3,2X25 STEEL
45
78003040033
FOOTREST L/S + R/S CPL. 09
46
50303089000
ANGLE PIECE '97
47
55007016001
PVC-HOSE 7X10 PER METER
50
54803096000
SPROCKET COVER 250 SX 07
59
77203053000
CHAIN SLIDER LOWER PART CPL.
62
77303139000
BLIND RIVET NUT EM6-60LF/HX
63
77203094000
PLASTIC FRAME PROTECTION SET
99
54803096010
SPROCKET COVER KIT
