FRAME

FRAME
Например: 6300300100004
1
6300300100004
Frame "fe06" 950 se 06
154 846 ₽/шт
2
61003088000
PLUG SFL28 05
3
6250300500001S
Engine support l/s 07
11 664 ₽/шт
4
6250300600001S
Engine support right 07
11 664 ₽/шт
5
0015100243
Vis
6
54310086100
SELF LOCKING NUT M10 CU WS=14
7
60003013000
Vis (M10x172)
8
60003014000
ENGINE BRAC. SCREW M10X206 03
9
60004076100
CHAIN SLIDING BLOCK 05
10
0017060206
SCREW F. PLASTIC K60X20AL SW6
11
62503005050
COVER ENGINE SUPPORT LEFT 05
12
62503006050
COVER ENGINE SUPPORT RIGHT 05
13
0991050102
FLAT H.SCEW DIN7991-M5X10 10.9
14
55530044000
Nut
15
54603048000
RANGE CHANGE METAL NUT M8
17
58303070100
BUMP RUBBER M8X25MM
18
0934080003
Nut
19
54403135000
PLASTIC CAP SFL10
20
60003044000
BOLT FOR FOOTREST REAR 03
21
0799060003
retaining washer DIN 6799 - 6
22
60003152000
ENGAGE PANEL FOOTREST L/S 03
23
60003052000
ENGAGE PANEL FOOTREST R/S 03
24
60003098000
RUBBER SLEEVE 03
25
58403060000
CHAIN ROLL 12X29X22,5 '98
26
58403060065
BUSH CHAIN ROLL 8X12X23 '98
27
0025080406
Vis
28
36003014000
Rondelle (Lock)
30
6250300210092
Sub frame 07
71 625 ₽/шт
31
60003004027
FL.HEAD SCREW M10X1,25 L=27 03
32
60003001051
COLLAR BUSHING 10X15X25X4 03
34
6250304800001S
Footrest bracket rear left 07
15 877 ₽/шт
35
6250304900001S
Footrest bracket rear right 07
13 077 ₽/шт
36
0019080266S
Vis (M8x26)
38
60003050000
FOOTREST CPL. L/S REAR 03
39
60003051000
FOOTREST CPL. R/S REAR 03
40
5030314013390
Footpeg l.+r. cpl. 03
19 843 ₽/шт
46
60103088000
PLUG ZK 8/5 06
50
78003040050
FOOTREST L/S 08
51
78003041050
FOOTREST R/S 08
56
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
57
54603041000
FOOTREST SPRING L/S & R/S
58
0125100003
washer DIN 125 A 10.5
59
0094032253
PIN DIN0094-3,2X25 STEEL
61
6300309400004
FRAME PROTECTIONS-SET ORANGE
62
44011076305
CABLE TIE 300/4,8MM BLACK
63
0025060166
Vis
64
79608052000
BUSH 6X11X16X5 MM
65
0025060356
Vis
66
0025060306
Vis
98
60004076110
CHAIN SLIDING KIT BELOW
99
58403060010
CHAIN ROLL KIT 06-13
