Главная Каталог товаров KTM EPC 2003 KTM Offroad KTM 2003 Enduro KTM 2003 Offroad 640 LC4 ENDURO BLACK 12L 03 (972638) [EU] KTM (VIN: VBKGSN40) FRAME

FRAME

FRAME
Например: 5840300184490
1
5840300184490
FRAME CPL. LC4 "H3" 03
2
5840300234490
Subframe cpl. steel silver 00
56 239 ₽/шт
4
58303002090
PLUG 12 X 17 MM
5
5840304800090
Footrestbrack. rear l/s 04
6 694 ₽/шт
5
5810300420090
Footrestbrack. rear r/s silver
9 361 ₽/шт
7
0934080003
Nut
10
59001037000
Vis (spec)
11
58003012000
SPACER ROLLER 10,3X20X22
12
71001012100
PVC CAP D=22MM
13
58307015000
TANK SUPPORT '93
14
58303055000
ENGINE SUPPORT AGW '94
16
58403013000
ENGINE BRAC.SCREW M10X110 WS13
17
55530044000
Nut
18
49109481052
Vis
19
54310086200
Nut (M8x10,9)
20
58403002370
BATTERY BOX 03
21
0025060106
Vis
22
0021060003
Rondelle
23
43205062100
silentbloc 20x15-M6x10-(1)
24
0797060003
TOOTH LOCK WASH. DIN6797-A 6,4
25
0934060003
hex nut DIN 934 M6
26
58403002010
RUBBER GROMMET 20X15-M6X8-(2)
27
54603048100
clip nut M6
30
0931100603
HH SCREW DIN0931-M10X60
31
0982100003
SELF LOCK.NUT DIN0982-M10 HIGH
32
58403014000
ENGINE BRAC.SCREW M10X160 WS13
36
55007016001
PVC-HOSE 7X10 PER METER
37
50303089000
ANGLE PIECE '97
38
5830303800090
*FOOTREST BRACKET L/S SILVER99
40
5830304000090
Footrest l/s silver '99
5 384 ₽/шт
41
5460314000090
Foot rest r/s silver '98
5 015 ₽/шт
42
58303041000
FOOTREST SPRING L/S '93
43
54603041000
FOOTREST SPRING L/S & R/S
44
58303044000
BOLT FOR FOOTREST
45
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
46
0125100003
washer DIN 125 A 10.5
47
0094032253
PIN DIN0094-3,2X25 STEEL
50
58303050044
FOOTREST REAR L/S CPL. '95
50
58303150044
FOOT REST REAR R/S CPL.'95
51
58303045044
FOOTREST RUBBER CPL. '94
52
58303051000
Footrest rubber
53
58403060000
CHAIN ROLL 12X29X22,5 '98
55
58403060065
BUSH CHAIN ROLL 8X12X23 '98
56
0797080003
Rondelle (Lock)
58
0985060003
SELF LOCK. NUT DIN0985-M 6
59
51103053000
CHAIN SLIDING PIECE BELOW '97
60
51103053051
BUSHING 8,2X10X20
61
54403135000
PLASTIC CAP SFL10
68
36003014000
Rondelle (Lock)
70
0025080306
Vis
71
0015080453
Vis
72
0910160153
PLUG DIN0910-M16X1,5
73
0603162220
Rondelle
76
0019080266S
Vis (M8x26)
77
0984060103
Vis (M6x10)
79
0125080003
Rondelle
80
58303010000
COVER OIL FILTER '94
81
0024060156
Vis
82
0024060106
Vis
85
50235033300
SNAP-NUT HOLDER M6 KP142
