Главная Каталог товаров KTM EPC 2002 KTM Street KTM 2002 Travel KTM 2002 Street 640 ADVENTURE-R (977521) [US] KTM FRAME

FRAME

FRAME

Например: 5820300144490

1

5820300144490

FRAME CPL. ADVENTURE 2002

2

5840300234490

Subframe cpl. steel silver 00

56 239 ₽/шт

3

58403002270

BRACKET F. BATTERY LC4 '99

4

58303002090

PLUG 12 X 17 MM

5

5840304800090

Footrestbrack. rear l/s 04

6 694 ₽/шт

5

5810300420090

Footrestbrack. rear r/s silver

9 361 ₽/шт

6

0137060003

spring washer DIN 137 B - 6

7

0934080003

Nut

8

58403002010

RUBBER GROMMET 20X15-M6X8-(2)

9

0985060003

SELF LOCK. NUT DIN0985-M 6

10

59001037000

Vis (spec)

11

58003012000

SPACER ROLLER 10,3X20X22

12

71001012100

PVC CAP D=22MM

13

58307015000

TANK SUPPORT '93

14

58303055000

ENGINE SUPPORT AGW '94

16

0931101103

HH SCREW DIN0931-M10X110

17

49009082000

flanged hex nut DIN 6927 M10 WS15

18

49109481052

Vis

19

54310086200

Nut (M8x10,9)

30

0931100603

HH SCREW DIN0931-M10X60

31

0985100003

SELF LOCKING NUT DIN0985-M10

32

0912101603

AH SCREW DIN0912-M10X160

34

55530044000

Nut

36

55007016001

PVC-HOSE 7X10 PER METER

37

50303089000

ANGLE PIECE '97

38

58303038000

FOOTREST BRACKET L/S '93

40

5830304000090

Footrest l/s silver '99

5 384 ₽/шт

41

5460314000090

Foot rest r/s silver '98

5 015 ₽/шт

42

58303041000

FOOTREST SPRING L/S '93

43

54603041000

FOOTREST SPRING L/S & R/S

44

58303044000

BOLT FOR FOOTREST

45

54803044000

PIN FOR FOOT PED 51.5X9.8 MM

46

0125100003

washer DIN 125 A 10.5

47

0094032253

PIN DIN0094-3,2X25 STEEL

50

58303050044

FOOTREST REAR L/S CPL. '95

50

58303150044

FOOT REST REAR R/S CPL.'95

51

58303045044

FOOTREST RUBBER CPL. '94

52

58303051000

Footrest rubber

53

58403060000

CHAIN ROLL 12X29X22,5 '98

55

58403060065

BUSH CHAIN ROLL 8X12X23 '98

56

36003014000

Rondelle (Lock)

58

0985060003

SELF LOCK. NUT DIN0985-M 6

59

51103053000

CHAIN SLIDING PIECE BELOW '97

60

51103053051

BUSHING 8,2X10X20

61

54403135000

PLASTIC CAP SFL10

63

58303063000

BRAKE LEVER STOP '93

64

0991060202

FLAT HEAD DIN7991-M 6X20

70

0025080306

Vis

71

0015080453

Vis

76

0019080266S

Vis (M8x26)

77

0019080206S

Vis (Flat M8x20)

79

0125080003

Rondelle

80

58303010000

COVER OIL FILTER '94

81

0024060106

Vis

83

0025060166

Vis

84

0021060003

Rondelle

85

54603048100

clip nut M6

87

0910100003

PLUG DIN0910-M 10X1

88

58038022900

CU-SEAL RING 10 X 14 X 1,5

89

0912060106

AH SCREW DIN0912-M 6X10 10.9

90

58412099044

SKID PLATE LIMITED CPL. 97

91

0024060106

Vis

93

58003012200

ENGINE PROTECTOR BRACKET '97

94

0024060156

Vis

95

54308042000

Damper
