Главная Каталог товаров KTM EPC 1999 KTM Offroad KTM 1999 Mini KTM 1999 Offroad 60 SX (600195) [EU] KTM (VIN: VBKMRA20) FRAME

FRAME

FRAME
Например: 5460314000090
0
5460314000090
Foot rest r/s silver '98
5 015 ₽/шт
1
46003001100
FRAME 60/65 SX '99
15 498 ₽/шт
2
46003002000
SUB FRAME 60/65 SX '98
4
46003023000
SIDE STAND L=315MM 60/65 SX
5
46003024100
SIDE STAND BRACKET 60/65 SX'99
6
5460304000090
Foot rest l/s silver
4 895 ₽/шт
10
0931081003
HH SCREW DIN0931-M 8X100
11
0125080003
Rondelle
12
54310086000
Null
14
0107080203
AH OVAL H.SCREW DIN0170-M 8X20
15
0931080805
HH SCREW DIN 931 M8X80 10.9
20
50203053000
CHAIN ROLL D=30MM
21
74003021000
BUSHING 8.2 X 12 X 6
22
0625006087
GROOVED BALL BEAR. 608 2RS C3
23
36003014000
Rondelle (Lock)
24
46003062000
BRACKET FOR CHAIN ROLL 60SX'99
25
0015080353
Vis
28
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
29
54603041000
FOOTREST SPRING L/S & R/S
31
0094032253
PIN DIN0094-3,2X25 STEEL
33
51003021000
SIDESTAND SPRING LONG
35
0025080166
Vis
37
0025080206
Vis
40
50210086000
COVERING CAP SFL16
42
0025060456
Vis
43
0021060003
Rondelle
44
56509064000
SELF LOCKING NUT M6
45
55007016001
PVC-HOSE 7X10 PER METER
46
50303089000
ANGLE PIECE '97
48
0933050163
Vis
49
0934050003
HEXAGON NUT DIN0934-M 5
50
46013070000
BRAKE CABLE REAR 60/65 SX '98
51
46003060100
BRAKE LEVER CPL. 60/65 SX '99
20 242 ₽/шт
52
45003062000
BRAKE LEVER SPRING 50 SXR '97
53
0988121805
SHIM WASHER DIN0988-12X18X0,50
54
0094020200
* PIN DIN0094-2,0X20 STEEL
55
46003061000
FOOTBRAKE CARRIER METAL SHEET
56
31011093000
BOLT WITH PIN
