Главная Каталог товаров KTM EPC 1998 KTM Offroad KTM 1998 Enduro KTM 1998 Offroad 250 EGS 11KW (732680) [EU] KTM (VIN: VBKGSA20) FRAME

FRAME

FRAME

Например: 5460314010090

0

5460314010090

Footrest R/s

5 673 ₽/шт

1

54703001000

* FRAME KOK SX,MXC,EXC USA '98

1

54703001200

FRAME SEM 250-380 EXC,EGS'98

2

50303002000

% s.frame cpl.alu 125-380 '

5

54703013000

REINFORCING BRACKET 250-380'98

7

50307020000

RUBBER BUFFER FOR TANK '98

8

71003007000

STEERING HEAD LOCK CPL. ZADI

12

54603013000

engine brac.scr. M10x105 WS13

13

0019080206S

Vis (Flat M8x20)

14

0019080266S

Vis (M8x26)

15

56530079000S

Hh Collar Screw M8X44 Ws13

184 ₽/шт

16

54606004000

PLUG 37MM

18

54403135000

PLASTIC CAP SFL10

20

52303053100

CHAIN ROLL D=35MM 125-380 '99

21

0625006087

GROOVED BALL BEAR. 608 2RS C3

22

0015080353

Vis

23

74003021000

BUSHING 8.2 X 12 X 6

24

50203053000

CHAIN ROLL D=30MM

25

54310086000

Null

26

54310086100

SELF LOCKING NUT M10 CU WS=14

30

42007049000

PLASTIC CAP

33

36003014000

Rondelle (Lock)

39

0025080306

Vis

40

5460304010090

FOOT PED L/S SILVER '98

41

54803044000

PIN FOR FOOT PED 51.5X9.8 MM

42

54603041000

FOOTREST SPRING L/S & R/S

43

0125100003

washer DIN 125 A 10.5

44

0094032253

PIN DIN0094-3,2X25 STEEL

46

50303089000

ANGLE PIECE '97

47

55007016001

PVC-HOSE 7X10 PER METER

50

54607061000

SPROCKET COVER

53

54613038150

BUSHING 6,5X8X11

55

0025050206

Vis

56

54603073000

COLLAR BUSHING 5 X 10 X 6 ALU

57

44011076200

CABLE TIE 200/3,6MM BLACK

58

0025060256

Vis
