Главная Каталог товаров KTM EPC 1997 KTM Offroad KTM 1997 MX KTM 1997 Offroad 250 SX M/Ö (630170) [US] KTM FRAME

FRAME

FRAME

Например: 5460314010019

0

5460314010019

Footrest right anthracite 99

4 794 ₽/шт

1

54603401800

* FRAME FOR KOKUSAN-IGNITON '9

2

54603002100

* SUBFRAME ALU MX,EXC,EGS '94

5

54603045100

* ENGINE BRACE 250/300/360 '94

6

58303002090

PLUG 12 X 17 MM

7

54603055000

ENGINE MOUNTING 250/300 '90

8

71003007000

STEERING HEAD LOCK CPL. ZADI

11

0025060406

Vis

12

54603013000

engine brac.scr. M10x105 WS13

13

0019080206S

Vis (Flat M8x20)

14

0019080266S

Vis (M8x26)

15

56530079000S

Hh Collar Screw M8X44 Ws13

184 ₽/шт

16

54606004000

PLUG 37MM

18

54403135000

PLASTIC CAP SFL10

20

52303053100

CHAIN ROLL D=35MM 125-380 '99

21

0625006087

GROOVED BALL BEAR. 608 2RS C3

22

0015080353

Vis

23

74003021000

BUSHING 8.2 X 12 X 6

24

50203053000

CHAIN ROLL D=30MM

25

54310086000

Null

26

54310086100

SELF LOCKING NUT M10 CU WS=14

30

42007049000

PLASTIC CAP

33

36003014000

Rondelle (Lock)

39

0025080306

Vis

40

54603040100

% foot rest l/s wide '

41

54803044000

PIN FOR FOOT PED 51.5X9.8 MM

42

54603041000

FOOTREST SPRING L/S & R/S

43

0125100003

washer DIN 125 A 10.5

44

0094032253

PIN DIN0094-3,2X25 STEEL

46

50303089000

ANGLE PIECE '97

47

55007016001

PVC-HOSE 7X10 PER METER

50

54607061000

SPROCKET COVER

51

54630061000

CHAIN SLIDING PLATE 14 T/15 T

52

54603048100

clip nut M6

53

54613038150

BUSHING 6,5X8X11

54

0025060206

Vis

55

0025050206

Vis

56

54603073000

COLLAR BUSHING 5 X 10 X 6 ALU

57

44011076200

CABLE TIE 200/3,6MM BLACK

58

0025060256

Vis
