Fairing Assembly

Fairing Assembly
Например: SPMV8000A9806
1
SPMV8000A9806
Front mudguard
2
SPMV800048245
pc - CUSHION, SCREW, M6X1 L16
3
SPMV800098328
FRONTMUDGUARD
4
SPMV800091005
pc - CLAMP, PLASTIC, BRAKE PIPE
5
SPMV8H00B2688
is
6
SPMV80A092670
WASHER, SPACER, D10,5xD7,9xD6,
7
SPMV8D0090425
10 pc - Vis
8
SPMV8000A9807
BODY, COWLING
9
SPMV800090427
pc - CLAMP, FAIRING
10
8000B0335
WINDSHIELD
11
SPMV80A0A4000
TYRES DATA PLATE
12
SPMV8000B0336
ôFAIRING ô DATA PLATE
13
SPMV800090901
pc - Vis
14
SPMV800091022
BUSH, SCREW, M4x0,7
15
SPMV800092882
WASHER, PLASTIC, FAIRING, M
16
SPMV8000A9985
Rondelle
17
SPMV8000A9808
FAIRING RH
18
SPMV8000B0126
HEAT SHIELD, COWLING RH
19
800089750
PIN
20
SPMV800089751
pc - WASHER, PL STICA 12,5X6X0,5 POLIETILENO
21
SPMV8000A9809
FAIRING LH
22
SPMV8000B0127
HEAT SHIELD, COWLING LH
23
8000A9810
LOWER FAIRING
24
SPMV8000B0131
INSULATOR, LOWER RH
25
SPMV8000B0132
INSULATOR, UPPER RH
26
SPMV8000B0133
INSULATOR LH.
27
SPMV800097895
THERMO-REFLECT. PANEL
28
SPMV8000A5239
DECAL
29
SPMV8000B0037
NET LH
30
SPMV8000B0039
NET LH
31
SPMV8000B0036
NET RH
32
8000B0038
NET RH
33
SPMV8000B0040
NET RH
34
SPMV8000B0042
NET RH
35
SPMV8000B0044
NET RH
36
SPMV8000B0041
NET LH
37
SPMV8000B0043
NET LH
38
SPMV8000B0045
NET LH
39
RDTL005018
EAR FENDER
40
SPMV800063150
RING NUT M5
41
SPMV8000A5257
pc - SCREW M5X16
