F-8 FRONT FORK

F-8 FRONT FORK
Например: 44832-MAY-000
2
44832-MAY-000
CLAMPERSPDMT CAB
4
45464-MM9-000
CLAMPER A, BRAKE HOSE
425 ₽/шт
5
45464-MV1-000
CLAMPER A, BRAKE HOSE
6
45465-MM9-000
CLAMPER B, BRAKE HOSE
442 ₽/шт
7
45465-MV1-000
CLAMPER B, BRAKE HOSE
10
51401-MY1-003
SPRING A, FR. FORK
11
51402-MY1-003
SPRING BFR FORK
6 618 ₽/шт
12
51405-KA4-711
SEAT, SPRING
330 ₽/шт
13
51410-MV1-003
PIPE COMP., FR. FORK (SHO
14
51412-KA4-711
RING, BACK UP
726 ₽/шт
15
51414-MAZ-751
BUSH, GUIDE
1 179 ₽/шт
16
51415-MN1-671
BUSH, SLIDER
1 008 ₽/шт
17
51416-MBT-D11
SPRING, FR. REBOUND
18
51420-MAY-003
CASE COMPR BOT
19
51432-MG7-003
PIECE, OIL LOCK
20
51437-KA4-711
RING, PISTON (SHOWA)
21
51440-MY1-003
PIPESEAT
22
51447-KA4-711
RING, OIL SEAL STOPPER (S
322 ₽/шт
24
51454-MZ1-003
BOLT, FR. FORK
3 728 ₽/шт
25
51480-MAY-003
FORK SUB ASSYR F
26
51490-KA4-831
Fork oil seal and dust seal kit for one tube
2 367 ₽/шт
28
51520-MAY-003
CASE COMPL BOT
29
51580-MAY-003
FORK SUB ASSYL F
30
51611-MS8-003ZC
Boot,fr.fo*pb181*
4 162 ₽/шт
31
51612-KA4-831
BAND, BOOT UPPER (SHOWA)
739 ₽/шт
32
51613-MK2-003
BAND, BOOT LOWER (SHOWA)
802 ₽/шт
33
51634-MV1-003
HOLDER, AXLE
35
90116-KV3-701
is
256 ₽/шт
36
90202-MK2-003
Vis
259 ₽/шт
37
90301-473-003
Nut
456 ₽/шт
39
90544-283-000
Rondelle (Spec. 8mm)
236 ₽/шт
40
91254-KA4-831
Fork dust seal
1 227 ₽/шт
41
91356-KA4-711
O-Ring (35.2x2.4)
363 ₽/шт
43
93500-050-200G
Болт
39 ₽/шт
45
94001-050-000S
Гайка
39 ₽/шт
46
96001-060-1207
Bolt
63 ₽/шт
