F-16-3 REAR FORK / DRIVE CHAIN ​​(4)

F-16-3 REAR FORK / DRIVE CHAIN ​​(4)
Например: 405W3-KA5-505
1
405W3-KA5-505
CHAINDRIVE
2
40531-KA4-732
JOINT, DRIVE CHAIN (DAIDO
3
43468-KS6-700
GUIDE, RR. BRAKE HOSE
969 ₽/шт
4
52000-KS6-700
FORK ASSY.RR.
5
52108-KS6-701
BUSHPIVOT THRUST
6
52109-KA4-701
BUSH, PIVOT THRUST
1 148 ₽/шт
7
52141-KA3-830
COLLAR RR. FORK
8
52144-KA3-731
CAP, DUST SEAL
975 ₽/шт
9
52146-KS6-700
GUIDE CHAIN
10
52147-KS6-701
LIDER, CHAIN GUIDE
1 850 ₽/шт
11
52156-KS6-700
PLATECHAIN GUIDE *** NLA***
12
52158-KA3-831
ROLLER COMP., CHAIN TENSI
4 912 ₽/шт
13
52170-KS6-700
LIDER CHAIN ** NLA**
14
52171-KA3-830
WASHER, CHAIN SLIDER
286 ₽/шт
15
52175-KA3-831
ROLLER COMP., CHAIN UPPER
16
52180-KS6-700
GUARDCHAIN MUD
17
52190-KS6-700
CAPRR.FORK BODY
18
90106-KS6-700
BOLT, HEX., 8X49
494 ₽/шт
19
90117-KA3-831
BOLT, RR. FORK
20
90301-430-000
NUT RR.FORK PIVOT ** NLA**
21
91071-KS6-004
BEARING, SWINGARM PIVOT (
1 021 ₽/шт
22
91253-KA4-701
DUST,32X37.5X8
1 074 ₽/шт
23
93500-050-060H
Screw, pan, 5x6
39 ₽/шт
24
93500-050-080A
Болт
41 ₽/шт
25
93600-060-400A
Screw, flat (6x40)
55 ₽/шт
26
94050-08000
Nut
55 ₽/шт
27
96001-060-1600
БОЛТ
63 ₽/шт
28
96300-080-3500
Болт
96 ₽/шт
29
96300-060-2000
Болт
63 ₽/шт
