F-14-1 REAR WHEEL / SWING ARM (SH125 / R / 150 / R)

F-14-1 REAR WHEEL / SWING ARM (SH125 / R / 150 / R)

Например: 11203-GC7-300

1

11203-GC7-300

Silentblock

612 ₽/шт

2

42311-KGF-900

COLLAR A, RR. AXLE

3

42312-KEY-900

COLLAR B, RR. AXLE

1 195 ₽/шт

4

42650-KTF-890ZA

WHEEL SUB ASSY., RR. *NH3

5

42711-KTF-641

IRE, RR. (DUNLOP) (120/8

6

42753-KBS-901

VALVE, RIM (WONDER)

7

43251-KTF-891

Disque de frein

8

52100-KTF-670

SWINGARM ASSY., RR.

9

52111-KTF-B20

RUBBER, SWINGARM

10

90105-MV9-003

Brake disc fixing screw

409 ₽/шт

11

90306-KSV-D01

NUT, U, 16MM

912 ₽/шт

12

91051-KS4-003

Roulement

1 662 ₽/шт

13

91258-HB3-003

DUST SEAL, 37X25X6

818 ₽/шт

14

91259-KM1-003

SEAL, 25X47X5

692 ₽/шт

15

94101-10000

Rondelle (10 mm)

47 ₽/шт

16

94520-47000

Seeger (47mm)

157 ₽/шт

17

95701-100-6000

Bolt, flange, 10x60

110 ₽/шт
