Главная Каталог товаров Polaris EPC 2014 Polaris ATV Polaris 2014 OUTLAW 90 - A14KA09AD/AF Polaris 2014 ATV ENGINE | ENGINE, AIR INTAKE SYSTEM - A14KA09AD/AF (49ATVAIRBOX14SP90)

ENGINE | ENGINE, AIR INTAKE SYSTEM - A14KA09AD/AF (49ATVAIRBOX14SP90)

ENGINE | ENGINE, AIR INTAKE SYSTEM - A14KA09AD/AF (49ATVAIRBOX14SP90)

Например: 0450824

1

0450824

BOLT-W/WSHR HEX

2

0453331

DUCT-INLET CLUTCH COVER

3

0453655

Collier

4

0453656

BOOT-DUCT

5

0453187

CLIP-RETAINING

6

0450880

NUT-FLG W/SERR

7

0453184

SEPARATOR-OIL

8

0450865

FUEL LINE CLIP

9

0454007

TUBE-OIL

10

0453516

CLIP-OIL SEPARATOR

11

0454006

TUBE-OIL

12

0452215

BOLT-HEX

13

0454008

TUBE-BREATHER VENTILATED

15

0453944

Collier

16

0454927

HOSE

17

0454398

VALVE-INTAKE DUAL

18

0453517

BOLT-FRAME

19

0452795

CLIP

20

0454928

HOSE

21

0454929

TUBE-INTAKE DUAL

22

0452413

Vis

23

0455377

GASKET-AIR INJECTION

24

0454930

HOSE

25

0454785

BOLT-W/LOCTITE

26

0454375

ASM-FILTER FUEL

27

0453658

Collier

28

0453659

BOOT-AIR CLEANER

29

0453725

HOSE-DRAIN

30

0453661

CLIP

31

0453518

Vis

32

0453666

BRKT-MOUNT AIR BOX

33

0452565

CLIP-AIRBOX

34

0453662

BOX-AIR CLEANER

36

0453663

HOLDER-AIR FILTER

37

0454620

Filtre à air

38

0453484

GASKET-COVER AIRBOX

39

0453332

DUCT-OUTLET CLUTCH COVER

40

0453665

COVER-AIR BOX

41

0454624

Asm., Air Box [Incl. 15-18,21-26,28]
