ENGINE CASE

ENGINE CASE
1
A46030000044
engine case cpl.
2
75030085100
GasGas Retaining bracket crankshaft bear
3
0019050121S
Vis (Torx)
4
59030296000
SCREW PLUG
5
0906100100
PLUG DIN0906-M10X1
6
78036081100
Vis de vidange d'huile (M14x1,5)
7
0770110015
O-Ring (1,5x11)
8
58038022000
Rondelle
9
58030021100
Vis de vidange d'huile
10
80030058060
OIL JET "60" M4
11
79330058040
Nozzle
12
81230164050
OIL JET ANGLED 50
13
0770035020
O-RING 3,5X2,00 NBR
14
0912040103S
Cylinder screw DIN 912-M4x10-8.8 SS
15
60030063050
OIL JET 50 05
17
54830027100
Dowel, 21x12
18
54630027000
DOWEL BUSHING 13,8X11X12
19
59030023100
Dowel, 6x8x11.5
20
79230010000
CASE BUSH
21
0025060556
Vis
23
0025060706
Vis
24
0000150802000
Screw, M8x20 SW=8 8.8
25
0603082131
COPPER GASK.DIN7603- 8,2X13X1
26
80030058040
Oil jet "40" M4
99
A46030099000
ENGINE SEAL KIT 250CC
