Electrical System

Electrical System

Например: T2505810

1

T2505810

Main Harness

2

T2509590

La batterie

3

T2501756

Battery strap

4

T2507565

Starter Lead

5

T3203222

Bolt, HHF, M6 x 12, Slv

6

T2507578

Lead, Battery Positive

7

T2500872

Earth Lead

8

T2501866

Horn Assy, 76mm

8

T2507002

Horn Assy, 440 Hz

8

T2500113

Horn Assembly, Hi Tone

9

T3201228

Bolt, HHF, M8 x 14, Slv

10

T2502455

Fall Detection Switch

11

T3330390

Screw, H/Hd, M4 x 25, Slv, Enc

2 шт. в узле

12

T2502345

Relay, Normally Open

4 шт. в узле

13

T1310008

Starter Solenoid Assy

14

T2506050

Relay, Changeover

2 шт. в узле

15

T2507579

Cover, Battery, Moulding

16

T2501317

Bracket, Purge Valve

17

T2501772

Moulding, Starter Cable Guide

18

T2502881

Bracket, Unfused Solenoid, Moulding

19

T2501775

Moulding, Bracket, Connectors,

20

T2501779

Moulding, Headstock Tidy

21

T2501277

Bracket, Fusebox

22

T1290354

Moulding, Coils Bracket

23

T2507771

Cover, ECU

24

T2501828

Foam Pad, ECU

25

T3331234

Screw, Torx, P/H, M6 x 20, Slv

5 шт. в узле

26

T3330649

Screw, Pan/Hd, Tx, M5 x 12, Sl

4 шт. в узле

27

T3331260

Screw, Thread Forming, 5 x 20

3 шт. в узле

28

T3330943

Screw, But/Hd, M5 x 14, Slv

3 шт. в узле

29

T3555025

Washer, 6.4 x 18 x 1.6

4 шт. в узле

30

T3205063

Bolt, HHF, Lghtd, M6 x 16, Slv

2 шт. в узле

31

T3701094

P Clip, Dia 4.4, Black

2 шт. в узле

32

T3701098

Firtree, Dia 5 x 18

4 шт. в узле

33

T3331414

Screw, S/Tap, Torx, 5 x 16

34

T2501331

Moulding, Harness, Spine

35

T3700108

Clip, Cable, 14.3 x 10

2 шт. в узле

37

T3700216

Clip, Wire, Saddle

38

T2503076

Wire Guide

39

T3330627

Screw, Pan/HD, TPT, Tx, M5 x 1

40

T2509876

Flylead, ETC, JP

41

T2502511

Shorting Link, Non DRL

42

T2501422

Charger, USB, 5V, 170mm

43

T3700252

Rubber Band, 88mm

44

T2506520

Cover, Earth Lead

45

T9820091

Harness, Multifunction Lamp

46

T3331043

Screw, Pan/Hd, Tx, M6 x 12, Sl

47

T3350003

Locknut, Flanged, M6 x 1.0

2 шт. в узле

49

T2501310

Fuse, Mini, 10A

2 шт. в узле

50

T2501315

Fuse, Mini, 15A

4 шт. в узле

51

T2501325

Fuse, Mini, 25A

52

T2501305

Fuse, Mini, 5A

2 шт. в узле
