Electrical System

Electrical System

Например: T2501954

1

T2501954

Main Harness

2

T2501305

Fuse, Mini, 5A

3 шт. в узле

3

T2501310

Fuse, Mini, 10A

2 шт. в узле

4

T2501315

Fuse, Mini, 15A

3 шт. в узле

5

T2501320

Fuse, Mini, 20A

4 шт. в узле

6

T2501325

Fuse, Mini, 25A

2 шт. в узле

7

T1290088

Sensor, Air Temperature

8

T3050342

Screw, Cap/Hd, M5 x 16, Slv

9

T1290975

Air Pressure Sensor

10

T1300675

Regulator Rectifier, 50A

11

T1210120

Pump Assy, Oil & Water

12

T3350003

Locknut, Flanged, M6 x 1.0

2 шт. в узле

13

T2507988

Cover, Regulator Rectifier, Connectors

14

T2072786

Bracket, Fall Detect

15

T3205062

Bolt, HHF, Lghtd, M6 x 12, Slv

2 шт. в узле

16

T2300883

weezers, Fuse

17

T2307136

Blank Plug, Switch

19

T2500113

Horn Assembly, Hi Tone

19

T2507002

Horn Assy, 440 Hz

20

T2501789

Battery Strap

21

T2501834

Kit, Battery

21

T2501823

La batterie

23

T2502042

Earth Lead

24

T2502044

Battery Positive Lead

25

T3700192

P Clip, ID 8mm

26

T2502405

Switch, Fall Detection

27

T3551066

Washer, 4.3 x 12.0 x 1.0

2 шт. в узле

29

T2505075

Socket, Auxillary Power

2 шт. в узле

31

T2505562

Chassis Control Unit

33

T2505567

Jacket, CCU

36

T2505569

Cover, ECU Moulding

37

T2507729

Relay, Ultra Micro, ISO 280

38

T2507820

Subharness, Engine

43

T2509669

Cover, Throttle Body Connector

46

T3205254

Bolt, HHF, Lghtd, M8 x20, Slv

47

T3205077

Bolt, HHF, Lghtd, M6 x 8, Slv

2 шт. в узле

48

T3330943

Screw, But/Hd, M5 x 14, Slv

2 шт. в узле

51

T3331422

Screw, S/Tap, Torx, 5 x 20

52

T3451400

Plug, Dia 17.5mm

2 шт. в узле

53

T3700015

Cable Tie, 185.7 Long

2 шт. в узле

54

T3700212

Band, Rubber

2 шт. в узле

56

T3330390

Screw, H/Hd, M4 x 25, Slv, Enc

2 шт. в узле

57

T2505828

Heatshield, Rubber

58

T2509847

oll Gate Flylead
