Electrical Equipment

Electrical Equipment

Например: T2504441

1

T2504441

Main Harness

2

T2502182

Antenna, LF

2 шт. в узле

3

T2505562

Chassis Control Unit

4

T2506566

Moulding, CCU/ECU

5

T2503434

Heatshield

6

T2505038

Sleeve, KCU

7

T3050333

Screw, Cap/Hd, M6 x 25, Slv

2 шт. в узле

8

T2506575

Rubber Sheet

9

T2507088

Lead, Starter

10

T1310008

Starter Solenoid Assy

11

T3350003

Locknut, Flanged, M6 x 1.0

3 шт. в узле

12

T2507066

Battery Lead, Positive

13

T3205062

Bolt, HHF, Lghtd, M6 x 12, Slv

14

T2509004

Extension Cover, Mldg

15

T3330960

Screw, But/Hd, M5 x 12, Slv Enc

2 шт. в узле

16

T3020330

Grommet, Rectangular

17

T2507729

Relay, Ultra Micro, ISO 280

2 шт. в узле

18

T3700259

Rubber Band, 43mm

2 шт. в узле

19

T3021200

Grommet, Dia 14x4, Panel

2 шт. в узле

20

T3700108

Clip, Cable, 14.3 x 10

21

T3330952

Screw, Butn/Hd, M5 x 20, Slv

22

T3351052

Nut, Captive, 4-5.5mm

23

T2502214

Switch, Rotational

24

T2506555

Bracket, Rotational Switch

25

T3331436

Vis (4x1)

4 шт. в узле

26

T3332656

Screw, Button, M5 x 0.8 x 12,

2 шт. в узле

27

T2506599

Mldg, Wire Guide, Expansion Tank

28

T3331044

Screw, Pan/Hd, Tx, M6 x 16, Sl

2 шт. в узле

29

T2505445

Cover, Oil Filter

30

T2508994

Wire Guide, Hose, Harness

31

T3050334

Screw, Cap/Hd, M6 x 20, Slv

32

T2507330

Battery, Lithium Ion, 8AH

33

T2503209

Battery Case Assy, Spares

34

T2507077

Battery Lead, Negative

35

T2509595

erminal, Extension, Pressing

36

T2509991

Battery Case, Mldg

37

T3100040

Stud, M6 x 35, Enc

38

T2505075

Socket, Auxillary Power

39

T2506577

Moulding, KCU/Immobiliser

40

T3330727

Vis (M6x20)

3 шт. в узле

41

T2504461

KCU + Keys, Kit, RF434

41

T2504471

KCU + Keys, Kit, RF315

42

T3350111

Nut, Captive, M6

2 шт. в узле

43

T3707679

Connector Mount

44

T2506565

Mldg, KCU, Cover

45

T2507055

Subharness, Number Plate & Indicators

46

T2506311

Horn Assy, 440 Hz

47

T3331625

Screw, Btn Hd, M8 x 12, Slv

48

T2507099

Engine Subharness

49

T3700115

Cable tie, 185.7 long

2 шт. в узле

50

T2506588

Wire Guide, Breather Cover

51

T3330289

Screw, But/Hd, TX, M5 x 16, Slv

2 шт. в узле

52

T3350161

Nut, Captive, M5

53

T3701170

Plastic Rivet, Screw Type

6 шт. в узле

54

T2503437

Auxilary Fly Lead, JP

55

T2503204

Foam Pad, Battery Case

56

T3551128

Rondelle (Lock)
