Electrical Equipment

Electrical Equipment

Например: T2501483

1

T2501483

Harness, Main

2

T2501305

Fuse, Mini, 5A

3

T2501315

Fuse, Mini, 15A

3 шт. в узле

4

T2501320

Fuse, Mini, 20A

5

T2501325

Fuse, Mini, 25A

3 шт. в узле

6

T2505035

Fuse 40 amp

7

T2501823

La batterie

7

T2501834

Kit, Battery

8

T2501780

STRAP, BATTERY

9

T2501295

Battery Bracket

10

T3203222

Bolt, HHF, M6 x 12, Slv

11

T2506040

Relay, Normally Open, Diode

6 шт. в узле

12

T2501643

Horn Assy, Low Tone

13

T3201228

Bolt, HHF, M8 x 14, Slv

4 шт. в узле

14

T2503572

Starter Lead

15

T1310008

Starter Solenoid Assy

16

T3700192

P Clip, ID 8mm

17

T3331042

Screw, Pan/Hd, Tx, M6 x 12, En

4 шт. в узле

18

T3700061

Clip, Cable Double

4 шт. в узле

19

T2501757

Battery Lead

20

T2505035

Fuse 40 amp

21

T3350003

Locknut, Flanged, M6 x 1.0

22

T3350305

Locknut, Flgd, M6 x 1.0, Slv

2 шт. в узле

23

T1290975

Air Pressure Sensor

24

T3332464

Screw, S/Tap, THF, 5 x 25

25

T1290088

Sensor, Air Temperature

26

T3331414

Screw, S/Tap, Torx, 5 x 16

27

T2505075

Socket, Auxillary Power

2 шт. в узле

28

T2503600

Cable, Tidy, Sump

30

T2500844

Cover, CCU

31

T3021161

Rubber Foot, Dia 14.22 x 7.1

32

T3351100

Wingnut, M6, Plastic

33

T2503433

Chassis Control Unit, 433

33

T2503315

Chassis Control Unit, 315MHZ

34

T3701170

Plastic Rivet, Screw Type

2 шт. в узле

35

T2504512

S Clip, 3.5 - 4.5

36

T3700222

Clip, Cable, Dia 25mm, BLK

37

T2502455

Fall Detection Switch

38

T2501354

Bracket, Fall Detection Switch

39

T2502429

Bracket, Fall Detect Mount

40

T3205061

Bolt, HHF, Lghtd, M6 X 10, Slv

2 шт. в узле

41

T3330390

Screw, H/Hd, M4 x 25, Slv, Enc

2 шт. в узле

42

T2501496

Flylead, Fall Detection

43

T2501344

Bracket, Harness Connectors

44

T3330943

Screw, But/Hd, M5 x 14, Slv

2 шт. в узле

45

T2509876

Flylead, ETC, JP

46

T2501419

USB Charger, 5V

47

T2501421

Rubber Band, USB

48

T2507722

Bracket, USB Connector

49

T2503577

Engine Subharness

50

T2501069

Moulding, Crankcase Tidy

51

T3205064

Vis

52

T2500702

Solenoid Bracket

53

T2503579

Bracket, Sub-Harness Connector

54

T3203222

Bolt, HHF, M6 x 12, Slv

55

T3010062

Flanged Sleeve, M6 x 7.8 x 2.8

2 шт. в узле

56

T2501806

Spacer, Battery Moulding
