Главная Каталог товаров Triumph EPC 2016 Triumph TIGER EXPLORER XR 740277 > Triumph 2016 Electrical Equipment

Electrical Equipment

Electrical Equipment

Например: T2501007

1

T2501007

Harness, Main

2

T2501305

Fuse, Mini, 5A

3

T2501315

Fuse, Mini, 15A

4

T2501320

Fuse, Mini, 20A

5

T2501325

Fuse, Mini, 25A

3 шт. в узле

6

T2505035

Fuse 40 amp

2 шт. в узле

7

T2504604

Spares Kit, Battery

7

T2502450

La batterie

7

T2502376

Battery Multipack (10)

8

T2501750

Battery Strap

9

T2501295

Battery Bracket

10

T3203222

Bolt, HHF, M6 x 12, Slv

2 шт. в узле

11

T2506040

Relay, Normally Open, Diode

6 шт. в узле

12

T2501643

Horn Assy, Low Tone

13

T3201228

Bolt, HHF, M8 x 14, Slv

14

T2503572

Starter Lead

15

T1310008

Starter Solenoid Assy

16

T3700192

P Clip, ID 8mm

17

T3331042

Screw, Pan/Hd, Tx, M6 x 12, En

2 шт. в узле

18

T3700061

Clip, Cable Double

19

T2501198

Battery Lead, Pos/Neg

20

T3350003

Locknut, Flanged, M6 x 1.0

2 шт. в узле

21

T3350003

Locknut, Flanged, M6 x 1.0

2 шт. в узле

22

T3203222

Bolt, HHF, M6 x 12, Slv

2 шт. в узле

23

T1290975

Air Pressure Sensor

24

T3200190

Bolt, RHHF, M6 x 25, SLV

25

T1290088

Sensor, Air Temperature

26

T3050342

Screw, Cap/Hd, M5 x 16, Slv

27

T2505075

Socket, Auxillary Power

28

T2503600

Cable, Tidy, Sump

29

T3331042

Screw, Pan/Hd, Tx, M6 x 12, En

2 шт. в узле

30

T2500844

Cover, CCU

31

T3021161

Rubber Foot, Dia 14.22 x 7.1

32

T3351100

Wingnut, M6, Plastic

33

T2501842

Kit, Chassis Control Unit, BR

33

T2502315

Chassis Control Unit, 315 MHZ

33

T2502433

Chassis Control Unit, 433 MHZ

34

T3701170

Plastic Rivet, Screw Type

35

T2504512

S Clip, 3.5 - 4.5

36

T3700222

Clip, Cable, Dia 25mm, BLK

37

T2502455

Fall Detection Switch

38

T2501354

Bracket, Fall Detection Switch

39

T2502429

Bracket, Fall Detect Mount

40

T3205061

Bolt, HHF, Lghtd, M6 X 10, Slv

2 шт. в узле

41

T3330390

Screw, H/Hd, M4 x 25, Slv, Enc

2 шт. в узле

42

T2501496

Flylead, Fall Detection

43

T2501344

Bracket, Harness Connectors

44

T3330943

Screw, But/Hd, M5 x 14, Slv

2 шт. в узле

45

T2509876

Flylead, ETC, JP

46

T2501419

USB Charger, 5V

47

T2501421

Rubber Band, USB

48

T2507722

Bracket, USB Connector

49

T2503577

Engine Subharness

50

T2501069

Moulding, Crankcase Tidy

51

T3205064

Vis

52

T2500702

Solenoid Bracket

53

T2503579

Bracket, Sub-Harness Connector

54

T3203222

Bolt, HHF, M6 x 12, Slv

2 шт. в узле

55

T3010062

Flanged Sleeve, M6 x 7.8 x 2.8

2 шт. в узле
