ELECTRICAL BOX SLT 700 B964166 and Intl. SLT 700 I964166 (4933923392B010) | ELECTRICAL BOX SLT 700 B964166 and Intl. SLT 700 I964166 (4933923392B010)

ELECTRICAL BOX SLT 700 B964166 and Intl. SLT 700 I964166 (4933923392B010) | ELECTRICAL BOX SLT 700 B964166 and Intl. SLT 700 I964166 (4933923392B010)

Например: 5410912

1

5410912

O-RING,(ELEC.BOX)

2

4040069

"""BOARD TERMINAL W/FUSE"""

3

7512042

BOLT S.S.

4

7512072

SCREW,S.S.(10)

5

7552615

Rondelle (Lock)

6

4060110

SWITCH-RECTIFIER LR-52

7

4060108

REGULATOR/RECT. LR-21

8

5131256

BOX,BOTTOM,ELEC.

9

5410850

GROMMET,SECTION,NO HOLE

9

5410851

GROMMET,SECTION,1 HOLE

9

5410817

O-RING,(10)

9

5410852

GROMMET,SECTION,2-HOLE

10

5410775

GROMMET, WIRE

11

5630497

PLATE,6-HOLE,CAST

12

7515118

BOLT S.S.

13

7555836

Rondelle

15

3240204

SWITCH, MAGNETIC

16

5410346

INSUL.CABLE SOL.

17

2434011

CKT.BREAKER 15A.(WATER.)

18

5410725

O-Ring

19

7080461

BOOT THREADED

20

LR--

CALIPER, BRAKE, RH

21

5410677

GROMMET, COIL

23

5131174

TOP, ELEC.BOX

24

5411025

GROMMET,(.910 DIA.)

25

5410678

GROMMET, 16 GA.(10)

26

5630416

PLATE, 5-HOLE

27

4010051-30

CONDUIT CONVOLUTED(30 CM)

28

4010081

"""CABLE RED SOL./START."""

29

7546705

NUT 6 MM. S.S.

30

7552613

Rondelle (Lock)

31

7516809

BOLT(10)

32

4010082

SUBSTITUTED BY 9999999

33

5630415

PLATE, 2-HOLE

34

5241182

BRKT,COIL RETAINER

35

7515119

BOLT(10)

36

7080471

CLIP IGNITION CABLE

37

7073713

DECAL,WARN,HI.VOLT. (See Page 21)

38

7073734

DECAL,ELECT.BOX RESET (See Page 21)

39

2460581

HARNESS,GND-CONTROL BOX
