E-7 LEFT CRANKSHAFT COVER / GENERATOR

E-7 LEFT CRANKSHAFT COVER / GENERATOR
Например: 11341-KJ3-000
1
11341-KJ3-000
COVL.CRANKCASE
2
11361-KJ3-010
COVERL REAR CRAN
3
30300-KJ2-164
Ignition pulse generator (Pick-up) (toyo)
4
31100-KJ3-003
GENERÁTOR (KOKUSAN)
5
31110-KJ3-003
FLYWHEEL COMP.
6
31120-KJ2-003
Stator
7
32976-107-010
CLAMPER, WIRE HARNESS
296 ₽/шт
8
35750-001-020
CONTACT ASSY., NEUTRAL SW
613 ₽/шт
9
35752-KCT-690
SPACER, NEUTRAL SWITCH
307 ₽/шт
10
90084-471-000
CAP, A.C. GENERATOR
723 ₽/шт
11
90087-428-000
CAP,30MM
1 368 ₽/шт
12
90112-KC6-000
Vis
13
90426-437-000
WASHER, ROTOR SETTING
692 ₽/шт
14
91212-KJ2-000
O-Ring
299 ₽/шт
15
91302-107-010
Gasket - generator cover
865 ₽/шт
16
91304-MG7-003
O-Ring
487 ₽/шт
17
91303-MG7-003
O-Ring
456 ₽/шт
18
91312-107-000
O-Ring
252 ₽/шт
19
93500-050-160A
Болт
39 ₽/шт
20
93500-050-320A
Screw, pan, 5x32
47 ₽/шт
21
93500-060-120A
Болт
47 ₽/шт
22
93500-060-250A
Болт
58 ₽/шт
23
94111-05000
WASHER, SPRING, 5MM
41 ₽/шт
24
96001-060-2500
БОЛТ
79 ₽/шт
