E-7 CRANKSHAFT (CR125R2)

E-7 CRANKSHAFT (CR125R2)
Например: 11100-KZ4-L10
1
11100-KZ4-L10
CRANKCASE COMP., R.
2
11105-KZ4-L20
JOINT, EX. BREATHER
3
11106-KZ4-L20
TUBEEXH BREATHER
4
11191-KZ4-L10
Gasket - crankcase
1 676 ₽/шт
5
11200-KZ4-L10
CRANKCASE COMP., L.
6
11210-KZ4-L20
TUBE COMP., BREATHER
7
14100-KZ4-L21
REED VALVE ASSY
8
14111-KZ4-L21
REED VALVE ONLY
9
14121-KZ4-L21
STOPPER, REED VALVE
10
14132-KZ4-620
Intake manifold Gasket
519 ₽/шт
11
14133-KZ4-L20
SPACER, REED VALVE BODY
12
14134-KZ4-L20
GASKET B, REED VALVE BODY
13
16221-KZ4-L20
Pipe d’admission
14
16223-KA5-690
BAND, INSULATOR
15
22810-KS6-700
LIFTER COMP., CLUTCH
5 404 ₽/шт
16
23521-KW3-000
PLATE A, BEARING SETTING
377 ₽/шт
17
90004-GHB-670
Vis
204 ₽/шт
18
90015-KA3-711
Vis (spec)
503 ₽/шт
19
90430-PD6-003
Rondelle
157 ₽/шт
20
90601-KJ9-000
CLIP, 4X50
283 ₽/шт
21
91001-KA3-711
Roulement
1 574 ₽/шт
22
91001-KZ4-J11
BEARING, RADIAL BALL, 17X
1 539 ₽/шт
23
91002-KA4-003
Roulement
1 194 ₽/шт
24
91002-KY4-901
Roulement
2 352 ₽/шт
25
91004-KZ4-A11
BEARING, RADIAL BALL, 20X
1 552 ₽/шт
26
91004-KZ4-L11
BRG,BALL RADIAL 6
1 575 ₽/шт
27
91012-KA3-710
PLATE, COUNTERSHAFT BEARI
289 ₽/шт
28
91022-KA4-740
Needle bearing
1 211 ₽/шт
29
91201-KS6-004
Joint
876 ₽/шт
30
91202-KA3-711
OIL SEAL, 10X17X4 (ARAI)
409 ₽/шт
31
91203-KK3-830
Joint
275 ₽/шт
32
91203-KS6-004
Joint
1 272 ₽/шт
33
91205-166-004
Joint
1 338 ₽/шт
34
92900-080-353E
Болт заклепка
110 ₽/шт
35
93500-050-250A
Болт
47 ₽/шт
36
93600-060-120A
Болт
50 ₽/шт
37
93892-030-0608
Screw-washer, 3x6
47 ₽/шт
38
94109-12000
Rondelle
94 ₽/шт
39
94301-08140
Dowel pin (8x14)
94 ₽/шт
40
94301-10160
Dowel pin (10x16)
121 ₽/шт
41
95002-45000
CLIP, TUBE (C8)
39 ₽/шт
42
96001-060-1400
Bolt
63 ₽/шт
43
96001-060-4500
Болт
86 ₽/шт
44
96001-060-5000
Болт
96 ₽/шт
45
96001-060-7500
Болт
94 ₽/шт
46
96001-060-8500
Болт
94 ₽/шт
47
96100-600-3000
ПОДШИПНИК ПЕРЕДНЕЙ СТУПИЦЫ
744 ₽/шт
