E-6 CLUTCH

E-6 CLUTCH
Например: 15131-KT7-013
1
15131-KT7-013
SPROCKET, OIL PUMP DRIVE
2
22100-MY5-602
OUTER COMP., CLUTCH
3
22116-MY5-600
GUIDE, CLUTCH OUTER
4
22120-MZ8-B40
CENTER, CLUTCH
8 529 ₽/шт
5
22125-MN8-000
SEAT, JUDDER SPRING
660 ₽/шт
6
22201-KAE-000
DISK, CLUTCH FRICTION
1 526 ₽/шт
7
22201-MS6-620
DISK, CLUTCH FRICTION
1 446 ₽/шт
8
22202-ML4-611
DISK B, CLUTCH FRICTION
1 384 ₽/шт
9
22321-MM9-000
PLATE, CLUTCH
959 ₽/шт
10
22350-MS6-922
PLATE, CLUTCH PRESSURE
4 205 ₽/шт
11
22361-MV4-000
PLATE, CLUTCH LIFTER
1 384 ₽/шт
12
22401-MM9-000
Clutch spring
440 ₽/шт
13
22402-MY5-850
Spring (Judder)
1 821 ₽/шт
14
22847-415-000
ROD, CLUTCH LIFTER
554 ₽/шт
15
90003-MM9-000
Vis
244 ₽/шт
16
90241-KM9-000
Nut (20 mm)
739 ₽/шт
17
90432-121-000
Rondelle
307 ₽/шт
18
90458-MY5-850
Rondelle (22x45,8x0,8)
19
91053-ZY6-003
Needle bearing (30x37x26)
2 761 ₽/шт
20
96100-620-0000
Bearing, radial ball, 6200
464 ₽/шт
