E-2 CYLINDER HEAD

E-2 CYLINDER HEAD
Например: 12200-KRH-A00
1
12200-KRH-A00
Cylinder head
2
12204-KRM-305
Guide de soupape
1 337 ₽/шт
3
12210-KVX-600
HOLDER COMP., CAMSHAFT
4
12212-KRM-840
PLATE, STOPPER
197 ₽/шт
5
12213-KTT-900
CLIPVALVE GUIDE
6
12252-KVX-600
Joint culasse (OS. 0.75/1,00)
7
16210-KWK-900
Pipe d’admission
8
16214-KWK-900
GASKET,CARBINSURA
9
31917-KPH-901
Bougie d'allumage
11
90002-KRM-840
Vis
165 ₽/шт
12
90035-KRM-840
Stud bolt (8x22)
315 ₽/шт
13
90035-KWK-900
Stud bolt
14
90091-KRM-840
BOLTFLANGE SOCKE
238 ₽/шт
15
90306-KRM-840
NUTCYLINDER HEAD
1 431 ₽/шт
16
90404-KPT-A00
Rondelle (12 mm)
283 ₽/шт
17
90703-KRM-840
DOWEL PIN, 10X12
212 ₽/шт
18
90704-KRM-840
DOWEL PIN, 6X10
222 ₽/шт
19
91304-HB3-003
O-Ring
535 ₽/шт
20
94050-06000
Nut
55 ₽/шт
21
95701-060-1400
Bolt
55 ₽/шт
22
95801-061-0500
Болт
126 ₽/шт
