E-16 TRANSMISSION

E-16 TRANSMISSION
Например: 23211-KVK-900
1
23211-KVK-900
SHAFTMAIN
2
23220-KVK-900
SHAFT COMPCOUNTE
3
23411-KVK-900
GEARC-1
4
23412-KVK-900
BUSH18X21X11.8
5
23421-KVK-900
GEARM-2
6
23431-KVK-900
GEARC-2
7
23432-KVK-900
BUSH22X25X11.1
8
23441-KVK-900
GEARM-3
9
23451-KVK-900
GEARC-3
10
23452-KVK-900
BUSH22X25X13.1
11
23461-KVK-900
GEARM-4
12
23462-KVK-900
BUSH20X23X17.4
13
23471-KVK-900
GEARC-4
14
23481-KVK-900
GEARM-5
15
23491-KVK-900
GEARC-5
16
23502-KVK-900
COLLARSPLINE 23M
17
23800-KVK-900
SPROCKET COMPDRI
18
23804-KPF-900
LATE, FIXING
19
90084-041-000
Vis
256 ₽/шт
20
90401-KE7-000
Rondelle (22,2mm)
291 ₽/шт
21
90401-KVK-900
WASHER LOCK 20X19
22
90402-KVK-900
Rondelle (20x19x1,0)
23
90451-KPS-900
Rondelle (15mm)
24
90451-KY1-000
WASHER, SPLINE, 22MM
305 ₽/шт
25
90452-701-000
Rondelle (18mm)
181 ₽/шт
26
90453-KRM-840
WASHER, SPLINE, 20MM
27
90454-KF0-000
Rondelle (17mm)
283 ₽/шт
28
90601-329-000
CIRCLIP, 22MM
307 ₽/шт
29
90605-KVS-900
ET RING, 20MM
30
91003-KPF-901
Roulement
31
91004-KPF-901
Roulement
32
91004-KW3-004
BEARING, BALL, 62/22 (KOY
1 400 ₽/шт
33
91005-KPF-901
Roulement
34
91201-KW3-000
Joint
605 ₽/шт
