E-16 TRANSMISSION

E-16 TRANSMISSION
Например: 23211-KTY-D30
1
23211-KTY-D30
MAINSHAFT (11T)
11 271 ₽/шт
2
23221-KPP-900
COUNTERSHAFT
9 754 ₽/шт
3
23415-HB3-000
USH, 15MM
991 ₽/шт
4
23421-KPP-860
GEAR, COUNTERSHAFT FIRST
6 242 ₽/шт
5
23431-KGH-900
BUSH, 20MM
1 289 ₽/шт
6
23441-KPP-900
GEAR, MAINSHAFT SECOND (1
3 410 ₽/шт
7
23451-KPP-900
GEAR, COUNTERSHAFT SECOND
5 867 ₽/шт
8
23461-KPP-860
GEAR, MAINSHAFT THIRD & F
7 875 ₽/шт
9
23471-KPP-860
GEAR, COUNTERSHAFT THIRD
5 867 ₽/шт
10
23491-KPP-860
GEAR, COUNTERSHAFT FOURTH
5 491 ₽/шт
11
23501-KPP-860
GEAR, MAINSHAFT FIFTH (24
12
23511-KPP-860
GEAR, COUNTERSHAFT FIFTH
13
23521-KPP-900
GEAR, MAINSHAFT SIXTH (26
14
23531-KPP-900
GEAR, COUNTERSHAFT SIXTH
15
23801-KBP-900
SPROCKET, DRIVE (15T)
4 089 ₽/шт
16
23811-KR3-600
Plate, drive sprocket fixing
330 ₽/шт
17
90084-041-000
Vis
256 ₽/шт
18
90412-187-000
WASHER, THRUST, 15MM
291 ₽/шт
19
90441-KW7-930
PLATE, BEARING HOLDER
607 ₽/шт
20
90452-KPH-C00
Rondelle (12 mm)
21
90454-107-000
Rondelle (20 mm)
228 ₽/шт
22
90461-115-000
WASHER, SPLINE, 17MM
291 ₽/шт
23
90463-437-000
WASHER, SPLINE, 22MM
315 ₽/шт
24
90464-444-000
WASHER, SPLINE, 22MM
385 ₽/шт
25
90465-KE1-010
Rondelle
487 ₽/шт
26
90601-001-000
Seeger
204 ₽/шт
27
90601-437-000
CIRCLIP, EXTERNAL, 22MM
315 ₽/шт
28
91216-KGH-901
Joint
393 ₽/шт
29
95701-060-1400
Bolt
55 ₽/шт
30
96100-620-3000
Bearing, radial ball, 6203
645 ₽/шт
31
96100-620-4000
ПОДШИПНИК ВЫЖИМНОЙ
708 ₽/шт
32
96140-620-1000
ПОДШИПНИК
613 ₽/шт
33
96140-62020
Bearing (6202u)
645 ₽/шт
