E-15 TRANSMISSION (CBR1000FH / FJ / FM)

E-15 TRANSMISSION (CBR1000FH / FJ / FM)
Например: 23211-MM5-000
1
23211-MM5-000
SHAFTMAIN
2
23220-MM5-000
SHAFT COMP COUNT
3
23421-MM5-000
GEARC-1
4
23431-MZ2-610
GEARM-2
5
23451-MM5-640
GEARM-3M-4
6
23460-MM5-305
GEAR SET COUNTERS
8
23462-MM5-000
COLLAR30X12.7 C-
9
23463-MM5-000
COLLARSPLINE30X
10
23481-MM5-000
GEARC-4
11
23491-MM5-640
GEARM-5
12
23495-MM5-000
COLLAR, 28X13
1 453 ₽/шт
13
23501-MM5-000
GEARC-5
14
23511-MM5-640
GEAR MAINSHAFT
15
23512-MM5-000
COLLARSPLINE 28X
17
23801-438-000
SPROCKET, DRIVE (17T)
18
23820-MM5-000
GUIDE, RING
1 765 ₽/шт
19
23821-MB6-000
RING DAMPER ** NLA**
20
24261-283-000
PIN, GEARSHIFT FORK GUIDE
393 ₽/шт
21
90020-438-000
Vis
307 ₽/шт
22
90037-422-003
Vis (spec)
550 ₽/шт
23
90451-MM5-000
WASHER,THRUST SPL
290 ₽/шт
24
90452-MM5-000
WASHER,THRUST(SPL
25
90457-ML7-000
WASHER CTHRUST 2
26
90455-ML7-000
WASHER B, THRUST, 22MM (B
348 ₽/шт
27
90458-729-920
Rondelle (28mm)
28
90459-438-000
Rondelle (102 mm)
425 ₽/шт
29
90461-MM5-000
Rondelle (30mm)
30
90462-MM5-000
WASHERLOCK30MM
31
90463-MM5-000
Rondelle (30x36x1)
32
90464-MM5-000
WASHERSPLINE 28X
33
90465-MM5-010
Rondelle (Lock)
34
90603-MN4-000
CIRCLIP, 28MM
275 ₽/шт
35
90604-MM5-000
CIRCLIP, 30MM
393 ₽/шт
36
90605-MM5-000
RING, SNAP, 72MM
503 ₽/шт
37
90606-MM5-000
RING, SNAP, 62MM
503 ₽/шт
38
90705-MM5-000
PIN,BEARING SETTI
385 ₽/шт
39
91001-MB6-680
Needle bearing (22x26x13)
1 077 ₽/шт
40
91004-MM5-003
Roulement
41
91022-MM5-003
Needle bearing (22mm)
42
91023-MM5-641
Needle bearing (22mm)
1 763 ₽/шт
