Главная Каталог товаров HONDA EPC 125 cm³ - 349 cm³ HONDA XR 200 R HONDA XR200RF XR200R 1985 HONDA (VIN: ME05) E-12 TRANSMISSION (1)

E-12 TRANSMISSION (1)

E-12 TRANSMISSION (1)
Например: 23210-KK0-000
1
23210-KK0-000
M/SHAFT TRANS.
2
23220-KK0-405
SHAFT SET COUNTER
3
23411-KK1-000
GEARCT/SHAFT LOW
4
23412-KK0-000
BUSH18MM
5
23421-KK0-770
GEARMAINSHAFT SE
4 492 ₽/шт
6
23431-KK1-000
GEARCT/SHAFT 2ND
7
23432-KK0-000
COLLAR22MM
8
23441-KK1-000
GEARM/SHAFT 3&4
9
23451-KL4-000
GEARC-3
10
23471-KT1-000
GEARC-4
11
23481-KK0-000
No longer available
12
23491-KK0-000
GEARCT/SHAFT 5TH
13
23501-KK0-770
GEARM-6
14
23505-KL4-000
COLLARSPLINE23MM
15
23511-KK0-771
GEARC-6
16
23801-KK1-000
SPRKTDRIVE 13T
17
28200-KL4-308
SETGEAR KICK STA
18
28222-KK0-000
BUSH, 15MM
1 685 ₽/шт
19
90451-107-000
Rondelle (15mm)
228 ₽/шт
20
90452-357-000
Rondelle (22mm)
771 ₽/шт
21
90454-KF0-000
Rondelle (17mm)
283 ₽/шт
22
90455-KR1-760
WASHER,SPLINE 20M
228 ₽/шт
23
90463-329-000
WASHER22MM
24
90464-360-000
WASHER, COUNTERSHAFT THIR
425 ₽/шт
25
90465-KK0-000
Rondelle
26
90601-437-000
CIRCLIP, EXTERNAL, 22MM
315 ₽/шт
27
90605-200-000
SET RING, 20MM
283 ₽/шт
28
91004-KW3-004
BEARING, BALL, 62/22 (KOY
1 400 ₽/шт
29
91005-KK0-003
BEARING, BALL, 6202 (NTN)
1 503 ₽/шт
30
91007-KK0-000
Roulement
1 337 ₽/шт
31
91006-KK0-003
BRG,BALL 20X47X14
32
91201-KK1-641
Joint
675 ₽/шт
33
92101-060-080A
БОЛТ
47 ₽/шт
34
95014-92100
Plate, drive sprocket fixing
86 ₽/шт
