Cylinder - Cylinder head

Cylinder - Cylinder head
Например: AP8502655
1
AP8502655
O-ring D7,65x1,78
2
AP8508882
Spring fixing plate
3
AP8507839
Exhaust spring
4
AP8502668
Exhaust gasket (28,2x2,6)
5
AP8508553
2 pc - Stud bolt (7x115)
6
AP8206954
Oversize piston rings D40,8
6
AP8206952
iston ring set D40,3
6
AP8206953
Oversize piston rings D40,6
7
861612
Bougie d'allumage (NGK BR8ES)
8
AP8502846
iston pin D12x34,5
9
AP8206019
Seeger
10
AP8206250
iston assy D40,3
11
AP8206292
Joint d'embase cylindre
12
AP8206375
Ensemble Cylindre et Piston
13
AP8206618
Water hose union
14
AP8206427
Cap self-locking nut M7x1
15
AP8206721
Rondelle
16
AP8508560
Rondelle
17
AP8206285
4 pc - Joint culasse
18
AP8206286
O-ring 104,3x3,5
19
AP8502559
Vis
20
AP8206383
Thermostat
21
AP8106692
Cylinder head, grey
22
AP8502759
Rondelle
