CRANKSHAFT, PISTON

CRANKSHAFT, PISTON
Например: 59530018200
1
59530018200
Vilebrequin
1
59030018200
Vilebrequin
2
59030015044
CON.ROD REP.SET 250/520 RAC.00
2
59530015044
CON.ROD REP.SET 400 RAC. 2000
4
80030019000
CYL.ROLLBEAR.NJ206ECP/C3HVC058
5
59030055000
DRIVE GEAR 32-T F.BALANC.SHAFT
6
56030081000
Rondelle (30,5x45x0,10)
6
56030081100
THRUST WASHER 30,7X47X0,15
6
56030081200
Rondelle (30,5x45x0,30)
7
0888030050
WOODRUFF KEY DIN6888-3X5X13
8
0984060162
AH SCREW DIN7984-M 6X16
9
0760304772
Joint (SHAFT SEAL RING)
10
0618301617
NEEDLE BEARING HK 3016 B
13
59032000033
PRIMARY GEAR 33-T
14
0912060106
AH SCREW DIN0912-M 6X10 10.9
15
59030029100
Nut (M20X1,5 WS=27 LEFT)
16
6946005
Woodruff key (5x6,5)
17
0760142460
radial shaft seal 14x24x6 B
18
0471250120
CIRCLIP DIN0471-25X1,2
20
49030021000
COLLAR NUT M12X1 R/S
21
0137120000
SPRING WASHER DIN0137-B12
33
59030033000
PISTON PIN BOLT 20X15,8/12X50
34
59030074000
CIRCLIP C20X1,5
40
59530007000I
PISTON I 89MM CPL. CAST 2000
40
59530007000II
PISTON II 89MM CPL. CAST 2000
41
59530031000
OIL SCRAPER RING 89/81,5X3
42
57530032000
RECTANGULAR RING 89MM
50
59030007000I
Piston i 95mm cpl. forged 2000
55 718 ₽/шт
50
59030007000II
Piston i 95mm cpl. forged 2000
55 718 ₽/шт
51
58030631000
OIL SCRAPER RING 95MM
52
59030032000
RECTANGULAR RING 95/87,2X1,25
