CRANKCASE » ENGINE CASE

CRANKCASE » ENGINE CASE
Например: 22522443D
1
22522443D
ASS.CARTER HYM796
2
85310031A
Rondelle (spring)
3
71111281A
Dowel pin
4
77550211A
pc - Vis (M6x16)
5
942470014
Gasket - silicone sealant
6
76610671C
Stud bolt
7
85610642A
Rondelle
8
74810501A
pc - Nut (M10)
9
70240401A
Roulement
10
720941616
.SCREW TSPEI M6X12
11
036749275
PLATE, RETAINER
12
751202567
Roulement
13
066049268
.OIL SEAL
14
71311401A
Entretoise
15
77052508B
Vis
16
93041233A
Joint
17
757941542
Roulement
18
735033380
Seeger
19
78710111A
pc - Rondelle (ALU, 14x22x2)
20
70250081A
Roulement
21
77950621A
.THREADED DOWEL M10X1
22
93040932A
.SEAL, OIL 17X25X4
23
55241321C
.SENSOR, TIMING & RPM
24
77151368B
Vis
25
70240931A
.BEARING 35X85X23
26
77150658B
Vis
27
77150808B
Vis
28
88641321A
O-Ring
29
70240921A
.BEARING 35X78X19
30
85250421A
Rondelle
31
77150728B
pc - Vis
32
71110951A
Dowel pin
33
59320631B
REATHER VALVE
34
46320222A
pc - O-Ring
35
81510221A
NIPPLE, HOSEM14X1.5
36
89320062A
Vis de vidange d'huile
37
88640331A
O-Ring
38
84740061A
.BALL
39
79940121A
Spring
40
77916501AE
Vis (spec)
41
85212461A
Rondelle (BRASS 6x13x2 MM)
42
59310601B
HOLDER READ VALVE
43
82716031A
Entretoise
44
77150068B
Vis
45
77250341B
SCREW, TAPPING 3.5X12
46
78811151A
Gasket
47
81110021A
REED VALVE ASSY
48
83110151A
PLATE
