CRANKCASE

CRANKCASE

Например: 215

1

215

Dowel pin

2

358

Dowel pin

3

604

ROLL PIN

4

PLUG, timing

5

PLUG

6

1028

SCREW,SEMS,HEX SCKT/LOCK

7

3787

SCREW, HEX

8

4091

Vis

9

4319

SCREW, CAP

10

BOLT

11

6019

Rondelle

12

6026

Rondelle

13

6314W

Rondelle

14

6701

Rondelle

15

7145W

Rondelle (Lock)

16

7775

NUT, FLEX

17

7780

LOCKNUT

18

LOCKNUT

19

NUT

20

8881

RACE BEARING, OUTER

21

9119A

RETAINING RING, XL

22

SHIM, roller bearing, 0.100

22

SHIM, roller bearing, 0.102

22

SHIM, roller bearing, 0.104

22

SHIM, roller bearing, 0.106

22

9146

SHIM, ROLLER BEARING, .108

22

9147

SHIM, ROLLER BEARING, .110

22

9148

SHIM, ROLLER BEARING, .112

22

SHIM, roller bearing, 0.114

22

SHIM, roller bearing, 0.098

23

10080

CLAMP, DRAIN HOSE

24

11105

pc - O-Ring

25

11177A

RETAINING RING

26

16210-84A

MOTOR MOUNT, RT FRONT

27

16212-84

MTG PLATE,MOTOR,FRT

28

BOLT

29

16240-82

BUSHING

30

CRANKCASE SET, w/ bearings

30

CRANKCASE SET, w/ bearings (black)

31

24647-87

BEARING, GEARSHAFT - BLUE

31

24650-87

BEARING, GEARSHAFT - RED

31

24659-87

BEARING, GEARSHAFT - WHITE/GRA

31

24660-87

BEARING, GEARSHAFT - GREEN

32

24754-75A

DOWEL PIN,SPLIT,HOLLOW

33

29950-91

COVER STATOR WIRE

34

35151-74A

OIL SEAL

35

42449-80A

STUD, TAP END W/SEALANT

36

BEARING, complete

37

48315-60

STEERING HEAD BEARING CUP

38

60348-65B

DRAIN PLUG KIT

39

BREATHER TUBE

40

63500-68

FUEL HOSE, RUBBER, 3/8 ID, BUL

41

24729-74

BEARING ASSY, CRANKSHAFT
