Cooling System

Cooling System

Например: T2104201

1

T2104201

Radiator Assy, LHS

2

T2104211

Radiator Assy, RHS

3

T2104202

Fan & Guard Assy, LHS

4

T2104212

Fan & Guard Assy, RHS

5

T3330958

Screw, But/Hd, M5 x 10, Blk, Enc

4 шт. в узле

6

T2101623

Cap Assy

7

T3330960

Screw, But/Hd, M5 x 12, Slv Enc

2 шт. в узле

8

T3202304

Bolt, RHHF, M6 x 20, Slv

2 шт. в узле

9

T3020230

Grommet, 15 x 5 x 10

4 шт. в узле

10

T3010702

Flanged Sleeve, 6.4 x 10 x 8.5

4 шт. в узле

11

T2104205

Hose, Radiator Link, Lower

12

T3706213

Clamp, Constant Tension, Dia 2

4 шт. в узле

14

T3450035

Grommet, Dia 8, Dia 12.5, 3

2 шт. в узле

15

T2104216

Expansion Tank

16

T2101015

Cap, Expansion Tank

17

T2104217

Hose, Expansion Tank, Overflow

18

T3700190

Clip, Rear Brake Hose

19

T2100433

Elbow, Overflow, Quickfit

20

T3450141

Grommet, TPE, Quickfit

21

T2104218

Hose, Radiator, Overflow

22

T3706216

Clamp, Constant Tension, Dia 3

23

T3700077

Clip, 10.5 Rer Oetiker

24

T3706214

Clamp, Constant Tension, Dia 2

3 шт. в узле

25

T2100206

Cover, Water Outlet

26

T2100676

hermostat

27

T2100201

Seal, Thermostat

28

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

5 шт. в узле

29

T2100408

Hose, Bypass, Water

30

T3700440

Clip, Hose, 11-12.5mm

3 шт. в узле

31

T2104207

Hose, Radiator Inlet, Y-Piece

32

T2100224

Cover, Water Inlet

33

T2100205

Gasket, Water Inlet

34

T3600124

O-Ring (21,5x3)

3 шт. в узле

35

T2104206

Hose, Radiator, Outlet, T-Piece

36

T3600190

O Ring, 24 x 2.5

3 шт. в узле

37

T3706211

Clamp, Constant Tension, Dia 1

3 шт. в узле

38

T3706215

Clamp, Constant Tension, Dia 3

39

T2107012

Pipe, Water Pump Inlet

40

T3205064

Vis

2 шт. в узле

41

T2107014

Pipe, Water, Pump Outlet

42

T2107200

Hose, Water Inlet, Heat Ex

43

T2105201

Hose, Water Pump, Outlet

45

T2101086

Foam Strip, Radiator

2 шт. в узле
