Главная Каталог товаров Triumph EPC 2021 Triumph TRIDENT 660 Triumph 2021 Cooling System

Cooling System

Cooling System

Например: T2106301

1

T2106301

Radiator Assy

2

T2101623

Cap Assy

3

T2107511

Air Deflector

4

T2106303

Fan Assembly

5

T2100168

Bracket, Radiator, Lower, Rear

6

T3205067

Vis

5 шт. в узле

7

T3010144

Flanged Sleeve, M6 x 9.5 x 10.5

8

T3020033

Damper

9

T3010159

Flanged Sleeve, 6.4 x 9 x 8.5

10

T2107512

Air Deflector Retainer Bracket

11

T3020188

Grommet, 16.5 x 3 x 9.5

2 шт. в узле

12

T2100224

Cover, Water Inlet

13

T2100205

Gasket, Water Inlet

14

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

2 шт. в узле

15

T2107013

Pipe, Water Pump Outlet

16

T3200444

Bolt, M6 x 10

17

T3551111

Copper Washer, M6 x 12

18

T3600124

O-Ring (21,5x3)

3 шт. в узле

19

T3600190

O Ring, 24 x 2.5

20

T3205064

Vis

2 шт. в узле

21

T2107503

Hose, T-Piece

22

T2107508

Hose, Water Inlet, Heat Ex

23

T3706211

Clamp, Constant Tension, Dia 1

3 шт. в узле

24

T3706214

Clamp, Constant Tension, Dia 2

4 шт. в узле

25

T2107012

Pipe, Water Pump Inlet

26

T2105201

Hose, Water Pump, Outlet

27

T3706215

Clamp, Constant Tension, Dia 3

28

T2107550

Hose, Rad to Expansion Tank

29

T2107567

Hose, Expansion Tank Overflow

30

T3700077

Clip, 10.5 Rer Oetiker

31

T3700550

Hose Clip, 9.5-10.5

32

T2106005

Cap, Expansion Tank, Overflow

33

T2107575

Expansion Tank

34

T2107501

Cover, Expansion Tank

35

T2100206

Cover, Water Outlet

36

T2100675

hermostat

37

T2100201

Seal, Thermostat

38

T2107513

Bracket, Expansion Tank, Upper

39

T2107507

Hose, Water, Head to Rad

40

T2103011

Spigot, Straight

41

T2107518

Spigot, Right Angle

42

T2100408

Hose, Bypass, Water

43

T3706515

Clamp, Spring Band, 32mm

44

T3700440

Clip, Hose, 11-12.5mm

2 шт. в узле

45

T3205094

Bolt, HHF, Lghtd, M6 x 20, Enc

3 шт. в узле

46

T3555012

Washer, 6.4 x 16 x 2

2 шт. в узле

47

T3552004

Washer, M6 x 14 x 2.0

48

T3205063

Bolt, HHF, Lghtd, M6 x 16, Slv
