Главная Каталог товаров Triumph EPC 2019 Triumph TIGER SPORT 750470 > Triumph 2019 (VIN: SMTTP748) Cooling System

Cooling System

Cooling System

Например: T2102015

1

T2102015

Radiator

2

T3203222

Bolt, HHF, M6 x 12, Slv

3

T3550542

Washer, Cu, Od12.5 x Id6.4

4

T2100870

Cap, Radiator

5

T3205083

Bolt, HHF, LGHTD, M6 x 28, Slv

2 шт. в узле

6

T3010701

Flanged Sleeve, 6.4 x 10 x 14.

2 шт. в узле

7

T3021200

Grommet, Dia 14x4, Panel

3 шт. в узле

8

T3700182

Clip, Omega, 18mm x 14mm

9

T2100614

Fan, 140 Dia, Square Cowl

10

T3331517

Screw, P/HD Tx, Shld, M6 x 16,

3 шт. в узле

11

T2100913

Durite radiateur (Radiator to Pump)

12

T3706213

Clamp, Constant Tension, Dia 2

2 шт. в узле

13

T3706216

Clamp, Constant Tension, Dia 3

2 шт. в узле

14

T2100783

Water Pump Assembly

15

T2100784

O Ring, Water Pump

16

T3200190

Bolt, RHHF, M6 x 25, SLV

17

T3205073

Bolt, HHF, Lghtd, M6 x 1.0 x 5

2 шт. в узле

18

T2100782

Hose, Pump to Block

19

T3706216

Clamp, Constant Tension, Dia 3

2 шт. в узле

20

T2107070

Elbow, Water, Cast, Black

21

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

4 шт. в узле

22

T3600190

O Ring, 24 x 2.5

23

T2100826

Elbow, Coolant, Bypass, Black

24

T2100713

O-Ring (Water Elbow)

25

T2102020

hermostat, Bypass

26

T2105203

Hose, Coolant, Cyl Hd to Rad

27

T3706215

Clamp, Constant Tension, Dia 3

28

T2100273

Pipe, Formed, Coolant

29

T2109000

Expansion Tank

30

T2101015

Cap, Expansion Tank

31

T3331234

Screw, Torx, P/H, M6 x 20, Slv

31

T3330334

Screw, Tx, Pan/HD, M6 x 16, Sl

32

T2100244

Pipe, Formed, Coolant

33

T3700440

Clip, Hose, 11-12.5mm

3 шт. в узле

34

T2104657

Bracket, Sidepanel, RH

35

T2104541

Bracket, Sidepanel, LH

36

T3205061

Bolt, HHF, Lghtd, M6 X 10, Slv

4 шт. в узле

37

T3020203

Grommet, Rectangular Slot

2 шт. в узле

38

T2100960

Sheet, Air Deflector

39

T2101980

Bypass Hose

39

T2101101

Kit, Bypass Hose

40

T3700440

Clip, Hose, 11-12.5mm

3 шт. в узле

41

T3700035

Clip, Hose, Dia 13.5-15.0

41

T3700440

Clip, Hose, 11-12.5mm

3 шт. в узле

42

A9610046

Coolant, Hybrid Oat, 12 x 1L

43

T3555026

Washer, 6.4 x 18 x 1.6
