Главная Каталог товаров Triumph EPC 2015 Triumph Tiger 800 > 674841 TIGER 800 Triumph 2015 (VIN: SMTTRE15) Cooling System

Cooling System

Cooling System

Например: T2100308

2

T2100308

Radiator, Flat

3

T2100309

Fan, Cooling

4

T2100164

Cap Assy, Radiator

5

T2100084

Bleed Screw, Nylon

6

T3331517

Screw, P/HD Tx, Shld, M6 x 16,

3 шт. в узле

8

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

2 шт. в узле

9

T3010702

Flanged Sleeve, 6.4 x 10 x 8.5

10

T3020153

Grommet, 13 x 3 x 10

2 шт. в узле

11

T2100422

Hose, Water Inlet, T-Piece

12

T3707580

Hose Clip, Dia 20-32

4 шт. в узле

12

T3706214

Clamp, Constant Tension, Dia 2

4 шт. в узле

13

T3707570

Hose, Clip Dia 12-22

3 шт. в узле

13

T3706211

Clamp, Constant Tension, Dia 1

3 шт. в узле

14

T2100423

Hose, Water Inlet, Heat Ex

15

T2100407

Durite radiateur (PUMP OUTLET)

15

T2105201

Hose, Water Pump, Outlet

16

T2107014

Pipe, Water, Pump Outlet

16

T2107017

Kit, Water Pump Outlet

17

T3600190

O Ring, 24 x 2.5

18

T3205064

Vis

2 шт. в узле

19

T3600124

O-Ring (21,5x3)

3 шт. в узле

20

T2107012

Pipe, Water Pump Inlet

21

T2100408

Hose, Bypass, Water

22

T3700440

Clip, Hose, 11-12.5mm

3 шт. в узле

23

T2108890

Hose, Expansion Tank

24

T3700108

Clip, Cable, 14.3 x 10

25

T2100424

Hose, Water, Head to Rad

26

T3330676

Screw, Bleed, Plastic, M6 x 16

27

T3550231

Rubber Washer, M6 x 12

28

T3706216

Clamp, Constant Tension, Dia 3

28

T3707585

Clip, Hose, Dia 27-35

29

T2100675

hermostat

30

T2100201

Seal, Thermostat

31

T2100206

Cover, Water Outlet

32

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

2 шт. в узле

33

T2100224

Cover, Water Inlet

34

T2100205

Gasket, Water Inlet

35

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

2 шт. в узле

36

T2108888

Expansion Tank, Coolant

37

T2101015

Cap, Expansion Tank

38

T3450141

Grommet, TPE, Quickfit

39

T2100433

Elbow, Overflow, Quickfit

40

T3202304

Bolt, RHHF, M6 x 20, Slv

2 шт. в узле

41

T3350060

Wellnut, M6 x 15

2 шт. в узле

42

T2108889

Finisher, Expansion Tank

43

T3330941

Screw, But/Hd, Skt, M5 x 16, S

44

T2304368

Sheet, Air Dam

45

T3351052

Nut, Captive, 4-5.5mm

46

T3205063

Bolt, HHF, Lghtd, M6 x 16, Slv

47

T3205067

Vis

48

T3010046

Flgd Sleeve, M6 x 9.6 x 10.5

49

T3020033

Damper

50

T2100323

Bracket, Radiator, Lower, Fron

51

T2100168

Bracket, Radiator, Lower, Rear

52

T3205067

Vis

53

T2108895

Hose, Expansion Tank Overflow

54

T3700015

Cable Tie, 185.7 Long

55

T3700077

Clip, 10.5 Rer Oetiker

56

A9610046

Coolant, Hybrid Oat, 12 x 1L

57

T3707580

Hose Clip, Dia 20-32

4 шт. в узле

57

T3706215

Clamp, Constant Tension, Dia 3
