Главная Каталог товаров Triumph EPC 2014 Triumph TIGER SPORT > 750469 Triumph 2014 (VIN: SMTTG747) Cooling System

Cooling System

Cooling System

Например: T2100860

1

T2100860

Radiator

1

T2101140

Radiator

2

T3203222

Bolt, HHF, M6 x 12, Slv

3

T3550542

Washer, Cu, Od12.5 x Id6.4

4

T3205083

Bolt, HHF, LGHTD, M6 x 28, Slv

2 шт. в узле

5

T3010701

Flanged Sleeve, 6.4 x 10 x 14.

2 шт. в узле

6

T3021200

Grommet, Dia 14x4, Panel

3 шт. в узле

8

T2100614

Fan, 140 Dia, Square Cowl

9

T3331517

Screw, P/HD Tx, Shld, M6 x 16,

3 шт. в узле

10

T2100497

Durite radiateur (Radiator to Pump)

11

T3706213

Clamp, Constant Tension, Dia 2

2 шт. в узле

11

T3707580

Hose Clip, Dia 20-32

2 шт. в узле

12

T3707590

Hose Clip, 30-38

12

T3706217

Clamp, Constant Tension, Dia 3

13

T2100680

Pompe à eau

14

3600160-T0301

O-Ring (Water Pump)

15

T3330804

Bolt, HHF, M6 x 25

16

T3205075

Bolt, HHF, Lghtd, M6 x 65, Slv

2 шт. в узле

17

T2107006

Hose, Coolant, Pump to Block

18

T3706216

Clamp, Constant Tension, Dia 3

2 шт. в узле

18

T3707585

Clip, Hose, Dia 27-35

2 шт. в узле

19

T2107005

Elbow, Water, Cast, Black

20

T3600190

O Ring, 24 x 2.5

21

T3205066

Bolt, HHF, Lghtd, M6 x 20, Slv

5 шт. в узле

22

T2101133

hermostat, Bypass

23

T2100825

Elbow, Coolant, Bypass

24

T2100713

O-Ring (Water Elbow)

25

T3330334

Screw, Tx, Pan/HD, M6 x 16, Sl

26

T2105203

Hose, Coolant, Cyl Hd to Rad

27

T3600230

Seal

28

T3550542

Washer, Cu, Od12.5 x Id6.4

31

T2109000

Expansion Tank

32

T2101015

Cap, Expansion Tank

33

T2100870

Cap, Radiator

35

T2100273

Pipe, Formed, Coolant

36

T2100244

Pipe, Formed, Coolant

37

T3700440

Clip, Hose, 11-12.5mm

3 шт. в узле

41

T2100960

Sheet, Air Deflector

42

T3700182

Clip, Omega, 18mm x 14mm

43

T2104657

Bracket, Sidepanel, RH

44

T2104541

Bracket, Sidepanel, LH

45

T3205061

Bolt, HHF, Lghtd, M6 X 10, Slv

4 шт. в узле

46

T3020203

Grommet, Rectangular Slot

2 шт. в узле

47

A9610046

Coolant, Hybrid Oat, 12 x 1L

48

T3707585

Clip, Hose, Dia 27-35

2 шт. в узле

48

T3706215

Clamp, Constant Tension, Dia 3
