Главная Каталог товаров Triumph EPC 2003 Triumph THUNDERBIRD SPORT Triumph 2003 (VIN: SMTTC378) Cooling System

Cooling System

Cooling System

Например: T2100100

1

T2100100

Pompe à eau

2

T3202065

Vis

2 шт. в узле

3

Water pipe

4

T3600036

O-Ring

5

T3203115

Bolt, RHHF, M6x1.0x12, S/S

6

T3205653

Bolt, HHF, Lghtd, M8 x 30, Slv

7

3550030-T0301

Washer fibre

8

T2100343

Outlet pipe

9

T2100054

Gasket

10

T3205063

Bolt, HHF, Lghtd, M6 x 16, Slv

2 шт. в узле

11

T2102146

Elbow

12

T2102143

Gasket

13

T3331234

Screw, Torx, P/H, M6 x 20, Slv

14

T2100049

Bracket

15

T2100110

Hose outlet

16

T2102242

Hose Clip, 23-25, Bright, Ss

6 шт. в узле

17

T2100311

Hose

18

T2100321

Hose top

19

T2100333

Hose

21

T2100351

Hose bottom

22

Bolt

22

T3330726

Screw, Btn/Hd, M6 x 12, Slv

4 шт. в узле

23

Cover lh

24

T2100161

Cover rh

25

T2102137

Radiator

25

T2102135

Radiator

26

T3020300

Grommet, Dia 19.5 x 4 Panel

4 шт. в узле

27

Flanged sleeve

28

T3555033

Washer, 8.4 x 24 x 2

2 шт. в узле

29

T2102134

Stone guard

30

T3330540

Vis

2 шт. в узле

31

T2101314

Radiator bracket

32

T2101315

Radiator bracket

33

2101202-T0301

Fan assembly

34

T3331517

Screw, P/HD Tx, Shld, M6 x 16,

3 шт. в узле

35

T3350111

Nut, Captive, M6

36

T2100080

hermostat housing

37

T2100789

Switch fan

38

T2102131

hermostat

39

T3600210

O-Ring

40

T2100272

Retainer

41

T3331102

Bolt, HHF, M6 X 25, S/S

2 шт. в узле

42

T3600200

O-Ring

43

T3550542

Washer, Cu, Od12.5 x Id6.4

44

T3150007

Vis

45

T3331043

Screw, Pan/Hd, Tx, M6 x 12, Sl

2 шт. в узле

46

T2100074

Cap Assy

47

T2100450

Expansion tank

48

T3450035

Grommet, Dia 8, Dia 12.5, 3

49

T2100405

Elbow, ID 8.0 Tube

2 шт. в узле

50

T3620300

Overflow pipe

51

T2100997

Cap, Expansion Tank

52

Pipe

53

T3330334

Screw, Tx, Pan/HD, M6 x 16, Sl

2 шт. в узле

54

T3331299

Screw, Pan/HD, Tx, M6 x 40, Sl

56

T3700077

Clip, 10.5 Rer Oetiker

57

T3700440

Clip, Hose, 11-12.5mm

58

T3620317

Pipe

59

T3620348

Pipe, Expansion Tank To T.stat

60

3450075-T0301

Damper

61

T3551283

Washer, M10, 10.5x18x1.6, Slv

2 шт. в узле

62

2102150-T0301

Sensor temperature

63

3550020-T0301

Sealing Washer, M10

64

T3331043

Screw, Pan/Hd, Tx, M6 x 12, Sl

2 шт. в узле

65

3600160-T0301

O-Ring (Water Pump)

66

T3600230

Seal

67

T2102113

Clip, Hose, 20-32, Bright, Ss

4 шт. в узле

68

A9610046

Coolant, Hybrid Oat, 12 x 1L
