Главная Каталог товаров Triumph EPC 1994 Triumph SPEED TRIPLE (CARBS) Triumph 1994 Cooling system

Cooling system

Cooling system

Например: 2100000-T0301

1

2100000-T0301

Pompe à eau

2

T3205075

Bolt, HHF, Lghtd, M6 x 65, Slv

2 шт. в узле

3

Water pipe

4

T3600036

O-Ring

5

T3203222

Bolt, HHF, M6 x 12, Slv

2 шт. в узле

6

T3205653

Bolt, HHF, Lghtd, M8 x 30, Slv

7

3550030-T0301

Washer fibre

8

T2100071

Hose, Radiator, Bottom, 3 Cyl

9

T2102242

Hose Clip, 23-25, Bright, Ss

4 шт. в узле

10

T2102280

Hose Clip, 12 x 25

11

T2102231

Hose Clip, 32 x 50

12

2100009-T0301

op hose

13

Connection water outlet

14

T2100054

Gasket

15

T3331517

Screw, P/HD Tx, Shld, M6 x 16,

2 шт. в узле

16

2102130-T0301

hermostat

17

2102150-T0301

Sensor temperature

18

3550020-T0301

Sealing Washer, M10

19

T2100074

Cap Assy

20

T2100110

Hose outlet

21

2101302-T0301

Radiator

22

T3020300

Grommet, Dia 19.5 x 4 Panel

4 шт. в узле

23

Flanged sleeve

24

T3050323

Screw, Cap/Hd, M8 x 30, Slv

4 шт. в узле

25

2101202-T0301

Fan assembly

26

T2100129

Grille

27

T3350111

Nut, Captive, M6

6 шт. в узле

28

2101270-T0301

Switch

29

2101274-T0301

Retainer

30

2101272-T0301

Seal

31

T2101314

Radiator bracket

32

T2101315

Radiator bracket

33

T3203222

Bolt, HHF, M6 x 12, Slv

2 шт. в узле

34

2100117-T0301

Expansion tank

34

T2100400

Expansion tank

35

T3300062

Pop Rivet

2 шт. в узле

35

T3331111

Screw, Pan/Hd, Tx, M6 x 55, Sl

2 шт. в узле

36

T3620305

Pipe

37

3700075-T0301

Hose clip

38

T2100405

Elbow, ID 8.0 Tube

2 шт. в узле

39

3450075-T0301

Damper

40

T3450035

Grommet, Dia 8, Dia 12.5, 3

41

T3620320

Pipe, Expansion Tank, Internal

42

T3620305

Pipe

43

T2100997

Cap, Expansion Tank

44

2102139-T0301

Inlet elbow

45

T2102143

Gasket

46

T3700440

Clip, Hose, 11-12.5mm

47

T3700015

Cable Tie, 185.7 Long

48

3600160-T0301

O-Ring (Water Pump)

49

T3900016

Label

50

3330504-T0301

Screw, M6 x 20

3 шт. в узле

51

3550060-T0301

Washer, Plastic, 14.3 x 2.0

3 шт. в узле

52

T3330334

Screw, Tx, Pan/HD, M6 x 16, Sl

3 шт. в узле

53

T2100049

Bracket

54

2100043-T0301

Couvrir

55

2100037-T0301

Bracket

56

T3203222

Bolt, HHF, M6 x 12, Slv

2 шт. в узле

57

Cover, Rad End, LH, Textured

58

Cover, Rad End, RH, Textured

59

Reflector, Side, Yellow

60

T3331043

Screw, Pan/Hd, Tx, M6 x 12, Sl

4 шт. в узле

61

T2100065

Couvrir

61

2100060-T0301

Couvrir

62

Capscrew, M6 x 12

62

T3051058

Screw, Cap/HD, M6 x 20, Enc

63

T2101314

Radiator bracket

64

T2101315

Radiator bracket

65

T3555033

Washer, 8.4 x 24 x 2

2 шт. в узле

66

Washer

67

T3331043

Screw, Pan/Hd, Tx, M6 x 12, Sl

4 шт. в узле

68

T3600230

Seal

69

T3331234

Screw, Torx, P/H, M6 x 20, Slv

70

T2012144

Stud, Sprocket Carrier

71

A9610046

Coolant, Hybrid Oat, 12 x 1L
