Главная Каталог товаров KTM EPC 2017 KTM Street KTM 2017 Naked Bike KTM 2017 Street 125 DUKE WHITE B.D. 17 (F4003Q4) [EU] KTM COOLING SYSTEM

COOLING SYSTEM

COOLING SYSTEM

Например: 93035065033

1

93035065033

Compensating tank complete

2

90135066000

PLUG F. EXPANSION TANK

3

90102055000

EXPANSION TANK O-RING

5

90135067000

HOSE 6X10,5X80 MM

6

93035067000

Pre-formed hose

7

93035065050

Retaining bracket

8

93008028050

Rubber bushing

9

93035065030

Rubber bushing

10

J025060203

Vis

11

93035026100

Radiator hose

12

93035028000

Radiator hose

14

93035024100

Hose thermostat to pipe T

15

90635071033

COOLANT PIPE T

16

90135024030

RADIATORHOSE RADI.-COOLL." T "

17

90135020002

HOSE CLAMP D24

18

90135020001

HOSE CLAMP D26

19

90135020003

HOSE CLAMP D28

20

J028060143

Vis

21

J770018530

O-Ring

22

93035010133

Radiator complete

23

90835041033

FAN CPL.

24

90835041004

Nut (Flanged)

25

90835041003

BRACKET FAN MOUNTING 3

26

90835041002

BRACKET FAN MOUNTING 2

27

90835041001

BRACKET FAN MOUNTING 1

28

90135016100

RADIATOR CAP

29

93035005000

SILENTBLOCK M6

30

93035033020

Spacer for radiator cover

31

93035035100

Radiator fairing right

32

93035034100

Radiator fairing left

33

90808043000

Vis (spec)

34

93035033010

Rondelle

35

93035003000

Cap nut M6

36

93035044000

Washer 6.5x16x2

37

J025060103

Vis

38

93035004000

Support

39

J025060101

Hexagon screw M6X10

40

93035009050

Flange

41

93035002000

Retaining bracket

42

90103005001

RADIATORSUPPORT L/S BELOW

43

J025060253

Vis

48

90135017000

Thermostat
