Главная Каталог товаров KTM EPC 2016 KTM Street KTM 2016 Naked Bike KTM 2016 Street 200 DUKE WH. W/O ABS CKD 16 (F4141O2) [CO] KTM COOLING SYSTEM

COOLING SYSTEM

COOLING SYSTEM

Например: 90135065033

1

90135065033

EXPANSION RESERVOIR CPL.

2

90135066000

PLUG F. EXPANSION TANK

3

J025060126

Vis

4

90103001033

BRACKET TUBE DRAIN

5

90135065050

GROMMET EXPANSION TANK

6

90107018011

CLAMP 10MM

7

90135067000

HOSE 6X10,5X80 MM

8

90135067050

HOSE 6X10X154 MM

9

90135074000

Vis (spec)

10

90135017000

Thermostat

11

90135024020

RADIATORHOSE THERM.-RADIATOR

12

90135025100

COOLING HOSE ENGINE - THERM.

14

90135024010

Durite radiateur

15

90635071033

COOLANT PIPE T

16

90135024030

RADIATORHOSE RADI.-COOLL." T "

17

90135020000

HOSE CLAMP D23

18

90135020001

HOSE CLAMP D26

19

90135020003

HOSE CLAMP D28

21

90108061000

RADIATOR PROTECTOR R/S

22

90108060000

RADIATOR PROTECTOR L/S

23

90108060002

DAMP. RUBBER II RADIATOR PROT

24

J926060000

FLANGED NUT M6 WS10 SELF LOCK.

25

J127060003

WASHER SPRING B6

26

90135001001

silentbloc M6

27

J025060103

Vis

28

J026060083

Vis

29

90103006001

RADIATOR SUPPORT R/S BELOW

30

90103005001

RADIATORSUPPORT L/S BELOW

31

90108060001

DAMPING RUBBER I RADIATOR PROT

32

90135016100

RADIATOR CAP

33

90635010000

RADIATOR CPL. WITH FAN

34

90835041033

FAN CPL.

35

J770018530

O-Ring

36

90835041001

BRACKET FAN MOUNTING 1

37

90835041002

BRACKET FAN MOUNTING 2

38

90835041003

BRACKET FAN MOUNTING 3

39

90835041004

Nut (Flanged)

40

90208061000

COVER RADIATOR R/S

41

90208060000

COVER RADIATOR L/S

42

90635040000

RADIATOR PROTECTION

43

90135032000

GROMMET RADIATOR COWL

99

90135017110

COOLING HOSE KIT DUKE
