Cooling System

Cooling System

Например: SPMV800099247

1

SPMV800099247

ELECTRIC FUN FOR RADIATOR

2

SPMV800099245

BRACKET ELECTRIC FAN

3

SPMV800042278

Nut

4

SPMV800062725

is

5

SPMV800099125

HOOD

6

SPMV800056783

10 pc - CLAMP, PLASTIC, L142

7

800099243

Radiateur - refroidisseur d’eau

7

SPMV8A00A7502

Radiateur - refroidisseur d’eau

8

SPMV800062651

pc - VIBRATION REDUCER D22-D10-SP12

9

SPMV800062652

WASHER, SPACER, D10 D6,25 L13,

10

SPMV8E00B2681

is (M6 1x20)

11

SPMV800098716

GRID, RADIATOR

12

SPMV800099249

pc - CUSHION, WATER RADIATOR

13

SPMV800091022

BUSH, SCREW, M4x0,7

14

SPMV8A0090901

is (M4x13,7)

15

SPMV8000A1409

FAIRING, WATER RADIATOR

16

SPMV800091022

BUSH, SCREW, M4x0,7

17

SPMV800099278

10 pc - Rondelle

18

SPMV8A0090901

is (M4x13,7)

19

800098694

R/H RAD COVER

20

SPMV800098695

UPPER COVER

21

SPMV8A0089786

5 pc - SCREW, FLANGE M6

22

SPMV800098336

RH RAD COVER

23

SPMV800098335

LH RAD COVER

24

SPMV800098323

BRACKET

25

800098834

Damper

26

SPMV80A098700

TOP HOLD-DOWN REPLAC.BRAC.RH

27

SPMV80A098699

BRACKET, LH

28

SPMV800062725

is

29

SPMV800062726

is

30

SPMV800062651

pc - VIBRATION REDUCER D22-D10-SP12

31

SPMV800098698

BRACKET

32

SPMV800062651

pc - VIBRATION REDUCER D22-D10-SP12

33

SPMV800097905

Refroidisseur d’huile

34

SPMV8A0099432

OIL COOLER PROTECTION

35

SPMV800099293

GRIND, OIL RADIATOR

36

SPMV800099322

ROTECTION, OIL RADIATOR

37

SPMV800048245

pc - CUSHION, SCREW, M6X1 L16

38

SPMV800089786

5 pc - Vis

39

SPMV800099159

HOSE, DELIVERY OIL COOLER

40

SPMV800099160

OIL RETURN HOSE

41

SPMV800098842

UNION, OIL OUTLET

42

800088526

WASHER, IN RAME

43

8A0098943

EXPANSION TANK

44

SPMV800097884

2 pc - GUIDE, HOSE

45

8A0066778

Vis

46

SPMV800099453

LATE

47

SPMV800090945

10 pc - ORING, 15,08x2,62mm

48

8A0090944

DUCT, COOLANT FLUID TANK

49

SPMV8AA091707

CAP, COOLANT FLUID TANK

50

SPMV8C0090424

10 pc - Vis

51

SPMV800090245

IPE, HOSE, COOLANT FLUID TANK

52

SPMV800092256

CLAMP, METAL, 66 D12

53

SPMV800090244

IPE, RUBBER, RADIATOR, 4

54

SPMV8U0092249

CLAMP, STEEL, R96 D35

55

SPMV8G0092249

Collier

56

SPMV80A099250

IPE, METAL, WATER RADIATOR

57

SPMV8A0097109

IPE, RUBBER, RADIATOR

58

SPMV8V0092249

Collier

59

SPMV8E0092249

5 pc - CLAMP, METAL D17 R96

60

8A0094186

HOSE, 1, OIL RADIATOR

61

SPMV8Q0092249

5 pc - CLAMP, STEEL, R96xD18,5

62

SPMV8M0066179

HOSE, WATER RADIATOR

63

SPMV800092248

CLAMP, RUBBER, L82

64

SPMV800089794

IPE

64

SPMV8000A7507

IPE, RUBBER, THERMOSTAT RADIA

65

SPMV8C0092249

5 pc - CLAMP, METAL, 32MM

66

SPMV8G0092249

Collier

67

SPMV80B0A7509

COVER ASSY, THERMOSTAT

67

SPMV80B087761

Thermostat cover

68

SPMV8E00B2681

is (M6 1x20)

69

SPMV800081283

Thermostat

70

SPMV800069413

ORING, THERMOSTAT COVER, 47,29

71

SPMV8F0092249

5 pc - Collier

72

SPMV800081280

HOSE, RUBBER

73

SPMV8F0092249

5 pc - Collier

74

SPMV80B091923

WATER INLETMANIFOLD

75

SPMV800017679

2 pc - O-Ring (39,34x2,62)

76

SPMV8E00B2681

is (M6 1x20)

77

SPMV800098334

COVER, COOLER FAN

78

SPMV800053724

BELT, RUBBER, SHORT

79

SPMV8000A0901

5 pc - WASHER, DO TAMBOR SELETOR D15

80

SPMV8000A7505

HEATER FAN

81

SPMV80A0A8944

RH HEATER FAN SUPPORT

82

SPMV80A0A8945

LH HEATER FAN SUPPORT

83

SPMV800056443

Nut

84

SPMV800062726

is

85

SPMV800056783

10 pc - CLAMP, PLASTIC, L142

86

SPMV800092668

CLAMP, RUBBER
