CLUTCH

CLUTCH
Например: A46032001072
1
A46032001072
Outer clutch hub
2
78132002400
GasGas Inner clutch hub
3
79432003100
Clutch pressure plate
4
78132002211
GasGas Clutch center
5
78132025100
DAMPING RUBBER
6
77232104000
DRIVING SLEEVE D=7,95 L=38
7
78132013000
WASHER 112X118X1.5
8
59032010100
INTERMEDIATE DISC 1MM 2002
9
59032010200
INTERMEDIATE DISC 1,4MM 2002
10
78932010000
INTERMEDIATE DISC 1MM
11
54832011100
LINING DISC 1,95 MM
12
55432024026
PRIMARY GEAR
13
A46032015000
Collar sleeve
14
0405252910
Needle bearing (25x29x10)
15
78132005000
BELLEVILLE SPRING 71X115X1,5 I
16
78132006200
Spring retainer
17
0025050166
Vis
18
0252012002900
Wedge lock washer 19.5x29x3.4
19
0936181506
Hex nut DIN0936-M18x1.5 right
20
78932009000
WASHER 22 X 36,5 X 3
21
78132057144
PRESSURE PIECE CPL.
22
A48032054000
Push rod
23
79232061044
OUTPUT CYLINDER CPL.
24
79032064000
BLEEDER SCREW CPL.
25
0770300015
O-Ring
26
79232063000
CLUTCH PIPE
27
0603082121
SEAL RING CU DIN7603- 8X12X1
28
0025060256
Vis
29
0025060166
Vis
30
50329050000
VENT INJEKTION HYDR. CLUTCH
99
54832011110
CLUTCH KIT 250/300 13-15
