CHASSIS | CHASSIS, MAIN FRAME AND SKID PLATES - Z19VPE92AM/BM (C700358)

CHASSIS | CHASSIS, MAIN FRAME AND SKID PLATES - Z19VPE92AM/BM (C700358)

Например: 1024496-458

1

1024496-458

WELD-MAIN FRAME 72 BLK

2

1023641-458

WELD-MAINFRAME FRT ISO MP 72 B

3

7519285

SCR-HXFL-M10X1.25X55 10.9 ZOD

4

7519332

SCR-HXFL-M10X1.25X40 8.8 ZOD

5

7547333

NUT-M10X1.25 FLG NYLOC-OLIVE D

6

5456432-070

PLATE-SKID BLK

7

5450556-070

PLATE-SKID BLK

8

5452063-070

PLATE-SKID REAR BLK

9

7518529

SCR-M6X1.0X20 HXHD FLG TDFM BL

10

7547674

NUT-M6-1.0 U-TYPE (2.5-3.8)(10

11

7556065

WASHER SKID PLATE

12

5264362-458

BRKT-TOW HOOK BACKER BLK

13

7518555

BOLT-M8X1.25X20 HXFLG TAP/R-OD

14

1024577-329

WELD-DASH TURBO S ECOAT

15

1020572-329

WELD-SEAT BASE MP BLK

16

5258097-329

BRKT-SEAT SUPPORT FRT MP BLK

17

7518934

SCR-M10X1.5X25-8.8 HFS ZOD

18

7519650

SCR-TXTH-M6X1.0X25 RIE

19

1019777-329

WELD-SEAT BASE REAR BLK

20

7518474

BOLT-M10X1.5X55 HX HD FLG

21

5260947-329

BRKT-BOX STRAP BLK

22

5264553-329

BRKT-BOX SUPPORT REAR ECOAT

23

1019529-458

WELD-SUPPORT REAR BLK

24

5260539-329

BRKT-CLOSE OFF SUPPORT BLK

25

7516732

Vis

26

7547332

NUT-M8X1.25 FLG NYLOC-OLIVE D

27

7518460

BOLT-M10X1.5X20 HXFLG W/PATCH

28

7521020

SCR-SH-M12X1.5X60 12.9 ZFB

29

7547958

NUT-HEX-M12X1.5 10 SPL

30

7557160

WSHR-22X13X3 ZFB HRD

31

1020619-458

WELD-TOW HOOK BLK
