Central electrical system

Central electrical system
Например: 2D000393
1
2D000393
Main wiring harness
2
AP8120422
Black hose 2.5X99
2
AP8120657
Hose clamp 4.5X280
2
AP8120416
pc - Black hose 180x4,5
3
CM287903
DI unit
4
00H01005311
orn
5
AP8152277
Vis (6x12)
7
GU03717450
Spark plug cap
8
CM255206
oil
9
AP8152274
Vis
10
00G04401462
pc - Clip nuts (M5)
11
080341
5 pc - H.V. cable
12
1D002308
Turn indicator control
13
AP8112811
Rubber fuse box
14
CM225715
Fusible (15A)
15
CM225707
Fuse 7,5A
16
La batterie (YB4L-B)
16
1L004080
a batterie
16
1L004081
pc - La batterie
16
1L004079
8 pc - La batterie (YB4L-B)
17
896570
Breather pipe 4x8 (4x8)
18
AP8201772
Sheath
19
00H02300961
Guard
20
641788
Régulateur de tension
21
598839
4 pc - Vis
22
AP8152299
0 pc - Nut
23
642317
Device bracket
24
2D000395
iode-condenser cable
25
863307
Speed sensor
26
2B002194
Pre-coated IX M6X18 SHC screw (CYLIND)
27
866994
Entretoise
28
438034
Bougie d'allumage (RN2C)
29
1A021287R
Water temperature switch
30
00011061300
Vis
31
658830
Rondelle (spring)
32
AP8150014
pc - Rondelle
