Central body - ENDURO

Central body - ENDURO
Например: AP8238787
1
AP8238787
RH side panel, orange
1
AP8239980
RH side panel, blue
1
AP8238839
RH side panel, blue
1
AP8258106
RH side panel, op.black
1
AP8248300
RH side panel, transp.black
1
AP8238088
RH side panel, black
1
AP8239311
RH side panel, alum.
1
AP8238374
RH side panel, alum.
2
AP8258107
LH side panel, op.black
2
AP8238841
LH side panel, blue
2
AP8239981
LH side panel, blue
2
AP8238789
LH side panel, orange
2
AP8238375
LH side panel, alum.
2
AP8248301
LH side panel, transp.black
2
AP8238090
LH side panel, black
2
AP8239312
LH side panel, alum.
3
AP8152179
Spring washer 6,5x12,5
4
AP8230668
Chain guard
4
AP8239959
Chain guard
5
AP8230755
RH side panel extension
6
AP8220425
Sprocket cover, grey
7
AP8152108
pc - Vis
8
AP8150179
Rondelle
9
AP8150280
Vis
