Carburettor - oil pump

Carburettor - oil pump
Например: AP8222339
1
AP8222339
Carburettor sha 14-12
1
AP8222366
Carburettor sha 14-9
1
AP8222365
Carburettor sha 14-9
1
AP8206453
Carburettor phbG 19
2
AP8502564
10 pc - Vis
3
AP8206451
ipe d’admission
3
AP8206653
ipe d’admission
3
AP8206602
ipe d’admission
4
AP8206242
Reed valve fix.plate
5
AP8206300
Reed valve assy
6
AP8206303
Clutch cable anchor bridge
7
AP8206321
pipe 650 mm
8
AP8206711
pc - Collier
9
AP8508669
4 pc - Dowel pin (D3x21,8)
10
AP8501467
pc - Seeger
11
AP8508872
ump gear Z=22
12
AP8206277
Rondelle
13
AP8206632
Oil pump shaft
14
AP8502665
O-Ring
15
AP8502562
Vis
16
AP8508863
Oil pump
16
AP8508863
Oil pump
17
AP8508667
Cable adjuster rubber
18
AP8206645
Oil pump cover
19
AP8206280
Vis
20
AP8508668
10 pc - Oil pipe grommet
21
AP8206631
pipe 190 mm
22
AP8206342
Collier
