Главная Каталог товаров Polaris EPC 2003 Polaris ATV Polaris 2003 500 MAGNUM 4X4 HDS (A03CD50FB) Polaris 2003 ATV CARBURETOR - A03CD50FB (4978627862C09) | CARBURETOR - A03CD50FB (4978627862C09)

CARBURETOR - A03CD50FB (4978627862C09) | CARBURETOR - A03CD50FB (4978627862C09)

CARBURETOR - A03CD50FB (4978627862C09) | CARBURETOR - A03CD50FB (4978627862C09)

Например: 3130507

1

3130507

RING

2

3130508

E-RING

3

3130962

JET NEEDLE

4

3130752

RING

5

3130732

DIAPHRAGM ASM.

6

3131464

Jet, Needle

7

3130541

Vis

8

3130540

WASHER SPRING

9

3130504

JETBLOCK ASM.

10

3130014

WASHER

11

3130572

MAIN JET #157.5

12

3130515

SEAL

13

3130517

PACKING

14

3130518

E-RING

15

3130519

CAP

16

3130361

PIN FLOAT

17

3130594

PLATE

18

3130532

Gasket - float chamber

19

3130520

Vis

20

3130590

FLOATBODY ASM.

21

3130521

Vis

22

3130529

FLOAT ASM.

23

3130591

Vis

24

3131360

VALVE-NEEDLE 1.5(PUSH IN)

25

3130533

O-Ring

26

3130624

JET PILOT #40

27

3131423

SCREW-ADJUST

28

3130836

Spring

29

3130502

VALVE THROTTLE 100

30

3130589

Spring

31

3130514

RING

32

3130501

Vis

33

3130513

SHAFT ASM THROTTLE

34

3130543

GUIDE CABLE

35

3130535

Vis

36

3130511

Couvrir

37

3130512

O-Ring

38

3130199

HOLDER GUIDE

39

3130538

Spring

40

3130539

PLUNGER ASM.

41

3130625

JET AIR PILOT #160

42

3131463

ASM. CARBURETOR

43

3084205

ASM. SCREW & WASHER

44

3130505

Spring

45

3130503

ASM. COVER

46

3130924

Vis
