CARBURETOR - A00CH50AK (4954805480D013) | CARBURETOR - A00CH50AK (4954805480D013)

CARBURETOR - A00CH50AK (4954805480D013) | CARBURETOR - A00CH50AK (4954805480D013)

Например: 3130507

1

3130507

RING

2

3130508

E-RING

3

3130962

JET NEEDLE

4

3130752

RING

5

3130732

DIAPHRAGM ASM.

6

3130960

NEEDLE JET

7

3130541

Vis

8

3130540

WASHER SPRING

9

3130504

JETBLOCK ASM.

10

3130014

WASHER

11

3130570

MAIN JET #152.5

12

3130515

SEAL

13

LR--

CALIPER, BRAKE, RH

14

3130518

E-RING

15

3130519

CAP

16

3130361

PIN FLOAT

17

3130594

PLATE

18

3130532

Gasket - float chamber

19

3130520

Vis

20

3130590

FLOATBODY ASM.

21

3130521

Vis

22

3130529

FLOAT ASM.

23

3130591

Vis

24

3131360

VALVE-NEEDLE 1.5(PUSH IN)

25

3130533

O-Ring

26

3130624

JET PILOT #40

27

3130522

O-Ring

28

3130523

Rondelle

29

3130525

Spring

30

3130524

ADJUSTER

31

3130546

SCREW ADJ

32

3130545

RING

33

3130544

Spring

34

3130502

VALVE THROTTLE 100

35

3130589

Spring

36

3130514

RING

37

3130501

Vis

38

3130513

SHAFT ASM THROTTLE

39

3130543

GUIDE CABLE

40

3130535

Vis

41

3130511

Couvrir

42

3130512

O-Ring

43

3130199

HOLDER GUIDE

44

3130538

Spring

45

3130539

PLUNGER ASM.

46

3130625

JET AIR PILOT #160

47

3131200

CARBURATOR ASM.

48

3084205

ASM. SCREW & WASHER

49

3130505

Spring

50

3130503

ASM. COVER

51

3130924

Vis
